Mitsubishi Lancer X facelift (2011-2015) analog interface wiring diagram
This page shows the only wiring diagram for the component.analog interface, which is found in the car Mitsubishi Lancer X facelift (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
analog interface wiring diagram (1 of 1)
1 C-309
13 C-315
17 C-311 PNK WIRE
5 C-316
7 D-16
8 7 16 12 5 C-313
8 F-27 19 D-16
9 C-301 6
ANALOG
ANALOG INTERFACE
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
BRN/WHT WIRE
CAN DRIVE
CIRCUIT
CIRCUIT CAN DRIVE
CIRCUIT INTERFACE
COMPUTER DATA LINES SYSTEM
ETACS-ECU (ON REAR OF JUNCTION BLOCK, BEHIND LEFT END OF DASH)
FUSIBLE LINK 34
FUSIBLE LINK BOX
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INTERFACE CIRCUIT
KEY REMINDER SWITCH
LEFT FRONT DOOR SWITCH (IN LEFT "B" PILLAR)
LEFT REAR DOOR SWITCH (IN LEFT "C" PILLAR)
LUGGAGE COMPARTMENT LIGHT
NCA WIRE
ON OFF
ON ON OFF OFF OFF
RED WIRE
RED/WHT WIRE
RELAY
RIGHT FRONT DOOR SWITCH (IN RIGHT "B" PILLAR)
RIGHT REAR DOOR SWITCH (IN RIGHT "C" PILLAR)
TRUNK LID LATCH
WHT WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit, evolution (1 of 2) -> ANALOG INTERFACE
