Mitsubishi Lancer X facelift (2011-2015) 99 100 98 101 b-109 Wiring diagram
This page shows the only wiring diagram for the component.99 100 98 101 b-109, which is found in the car Mitsubishi Lancer X facelift (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 99 100 98 101 b-109 (1 of 1)
15 5 A-10 A-39
99 100 98 101 B-109
A-60
B-108 B-09
B-109 B-10
BATTERY
BATTERY CURRENT SENSOR (EXCEPT 2.0L TURBO)
BATTERY TEMPER- ATURE SENSOR 2 4
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BRN/BLK WIRE
CAN TRANSCEIVER GENERATOR MALFUNCTION IND LIGHT CIRCUIT
COMBINATION METER
COMPUTER DATA LINES SYSTEM
ENGINE COMPARTMENT FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPT)
ENGINE CONTROL MODULE (LEFT REAR OF ENGINE COMPT)
EVOLUTION EXCEPT EVOLUTION
EXCEPT 2.0L TURBO 2.0L TURBO
FUSE 5
FUSIBLE LINK 33
FUSIBLE LINK 36
FUSIBLE LINK BOX (NEXT TO BATTERY)
GENERATOR
GRN WIRE
GRN/RED WIRE
GRY WIRE
GRY/BLU WIRE
JOINT CONNECTOR C-03 (RIGHT SIDE OF DASH)
LCD (GENERATOR MALFUNCTION LIGHT)
LED DRIVE CPU CIRCUIT
LT BLU WIRE
NCA WIRE
PNK 90 91 WIRE
PNK WIRE
RED WIRE
STARTING CIRCUIT
WHT WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Charging circuit -> 99 100 98 101 B-109
