Mitsubishi Lancer X facelift (2011-2015) 91 b-109 26 Wiring diagrams
This page contains all the electrical diagrams for the component. 91 b-109 26, in which he is found in the car Mitsubishi Lancer X facelift (2011-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
91 b-109 26 wiring diagram (1 of 2)
27 B-108
9 C-301
91 B-109 26
ANALOG INTERFACE CIRCUIT
BLK WIRE
BLU WIRE
C-312
CAN DRIVE CIRCUIT
COMBINATION METER
COMPUTER DATA LINES SYSTEM
CONDENSER FAN MOTOR (FRONT OF ENGINE COMPT)
CONDENSER FAN RELAY (ON UNDERHOOD FUSE/RELAY BLOCK)
ENGINE COMPARTMENT FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPT)
ENGINE CONTROL MODULE (LEFT REAR OF ENGINE COMPT)
ENGINE COOLANT TEMPERATURE SENSOR (ON REAR OF CYLINDER HEAD)
ETACS-ECU (ON REAR OF JUNCTION BLOCK, BEHIND LEFT END OF DASH)
FAN CONTROL RELAY
FUSE/RELAY BLOCK
FUSIBLE LINK 28
FUSIBLE LINK 29
GRN WIRE
GRN/RED WIRE
HOT AT ALL TIMES
INTERFACE CIRCUIT
LT GRN WIRE
NCA WIRE
PNK WIRE
RADIATOR FAN MOTOR (BEHIND RADIATOR)
RADIATOR FAN RELAY (ON UNDERHOOD
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
TEMPERATURE
TRANSCEIVER CIRCUIT
WHT WIRE
Go to component -> 2.0l, cooling fan circuit -> 91 B-109 26
