Mitsubishi Lancer X facelift (2011-2015) 24 c-39 pnk pnk pnk Wiring diagram
This page shows the only wiring diagram for the component.24 c-39 pnk pnk pnk, which is found in the car Mitsubishi Lancer X facelift (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 24 c-39 pnk pnk pnk (1 of 1)
10 D-23
11 F-23
13 D-14
17 D-14
22 D-11
24 C-39 PNK PNK PNK WIRE
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
C-301
C-304
C-311
D-11
D-14
D-15
ETACS-ECU (ON REAR OF JUNCTION BLOCK,
F-15
FUSE 10
FUSE 2
GRN WIRE
HIGH MOUNTED STOPLIGHT
HOT AT ALL TIMES
LEFT HEADLIGHT ASSEMBLY
LEFT LICENSE PLATE LIGHT
LEFT REAR COMBINATION LIGHT
LEFT SIDE TURN SIGNAL LIGHT
LEFT TAILLIGHT
LT BLU WIRE
NCA WIRE
PNK WIRE
REAR OF ENGINE COMPT)
RED WIRE
RIGHT HEADLIGHT ASSEMBLY
RIGHT LICENSE PLATE LIGHT
RIGHT REAR COMBINATION LIGHT
RIGHT SIDE TURN SIGNAL LIGHT
RIGHT TAILLIGHT
STOP
STOP LIGHT SWITCH (UNDER LEFT SIDE OF DASH)
STOP LIGHT SWITCH (UNDER LEFT SIDE OF DASH) CONTROL PNK CRUISE SYSTEM PNK WIRE
TAILLIGHT CONTROL CIRCUIT
TURBO EXCEPT TURBO
TURN
TURN SIGNAL LIGHT CONTROL CIRCUIT
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Exterior lamps circuit, except evolution (1 of 2) -> 24 C-39 PNK PNK PNK WIRE
