Mitsubishi Lancer X facelift 2 (2015-2017) windshield intermittent wiper interval adjusting knob Wiring diagram
This page shows the only wiring diagram for the component.windshield intermittent wiper interval adjusting knob, which is found in the car Mitsubishi Lancer X facelift 2 (2015-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram windshield intermittent wiper interval adjusting knob (1 of 1)
ANTI-THEFT SYSTEM
AUTO
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
C-130
C-201-1
C-212-1
C-301
C-304
C-316
C-317
CIRCUIT
CIRCUIT BREAKER
COLUMN ECU
COLUMN SWITCH
ETACS-ECU
FAST
FUSE 12
FUSE 4
FUSE 8
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/
HOT W/ ACC RELAY 3 ENERGIZED
INTERFACE
J/C 1 (C-03)
LIN DRIVE
MIST
POWER TOPS SYSTEM
POWER WINDOWS SYSTEM
REAR WASHER RELAY
RED WIRE
RIGHT END OF DASH)
SLOW
VIO WIRE
W/O AUTOMATIC LIGHTS
WASH
WASHER MOTOR
WHT WIRE
WINDSHIELD INTERMITTENT WIPER INTERVAL ADJUSTING KNOB
WINDSHIELD RAIN SENSITIVE WIPER FUNCTION ADJUSTING KNOB
WINDSHIELD WASHER RELAY
WINDSHIELD WASHER SWITCH
WINDSHIELD WIPER AUTOMATIC STOP RELAY
WINDSHIELD WIPER MOTOR
WINDSHIELD WIPER SPEED SWITCHING RELAY
WINDSHIELD WIPER SWITCH
YEL WIRE
Go to component -> Wiper/washer circuit -> WINDSHIELD INTERMITTENT WIPER INTERVAL ADJUSTING KNOB
