Mitsubishi Lancer X (2007-2010) w/o multi communication system Wiring diagrams
This page contains all the electrical diagrams for the component. w/o multi communication system, in which he is found in the car Mitsubishi Lancer X (2007-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram w/o multi communication system (1 of 2)
1 2 3 PNK 2 C-133 (NOT USED) WIRE
3 2 C-109
35 36 C-10
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
C-317
COMPUTER DATA LINES SYSTEM
ETACS-ECU (BEHIND LEFT END OF DASH)
FUSE 7
GRN WIRE
GRN/BLK WIRE
HANDS FREE MODULE (BEHIND GLOVE BOX)
HOT AT ALL TIMES
MICROPHONE UNIT (CENTER FRONT OF HEADLINER)
MULTIVISION DISPLAY
PNK WIRE
RADIO, CD PLAYER
RED WIRE
RED/WHT WIRE
W/ MULTI COMMUNICATION SYSTEM
W/O MULTI COMMUNICATION SYSTEM
WHT WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Hands free module circuit, evolution -> W/O MULTI COMMUNICATION SYSTEM
Wiring diagram w/o multi communication system (2 of 2)
1 2 PNK WIRE
3 2 C-106
45 46 C-12
AUDIO VISUAL NAVIGATION UNIT
BLK WIRE
BLU WIRE
BRN WIRE
C-317
COMPUTER DATA LINES SYSTEM
ETACS-ECU (ON REAR OF JUNCTION BLOCK, BEHIND LEFT END OF DASH)
FUSE 7
GRN WIRE
GRN/BLK WIRE
HANDS FREE MODULE (BEHIND RIGHT SIDE OF DASH)
HOT AT ALL TIMES
MICROPHONE UNIT (CENTER FRONT OF HEADLINER)
PNK WIRE
RADIO, CD PLAYER OR CD CHANGER
RED WIRE
RED/WHT WIRE
W/ MULTI COMMUNICATION SYSTEM
W/O MULTI COMMUNICATION SYSTEM
WHT WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Hands free module circuit, except evolution -> W/O MULTI COMMUNICATION SYSTEM
