Mitsubishi Lancer X (2007-2010) down/ auto down Wiring diagram
This page shows the only wiring diagram for the component.down/ auto down, which is found in the car Mitsubishi Lancer X (2007-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram down/ auto down (1 of 1)
14 6 16 4 DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH)
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
CAN DRIVE CIRCUIT
DOWN
DOWN LEFT REAR POWER WINDOW SWITCH
DOWN RIGHT FRONT POWER WINDOW SWITCH
DOWN RIGHT REAR POWER WINDOW SWITCH
DOWN UP
DOWN/ AUTO DOWN
ETACS-ECU (ON REAR OF JUNCTION BLOCK, BEHIND LEFT END OF DASH)
FRONT POWER WINDOW
FUSE
FUSE FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
ILLUM
INTERFACE CIRCUIT
JOINT CONNECTOR
LEFT FRONT POWER WINDOW MOTOR (CENTER OF DRIVER'S DOOR)
LEFT FRONT POWER WINDOW SWITCH
LEFT REAR POWER
LEFT REAR POWER WINDOW MOTOR (CENTER OF LEFT REAR DOOR)
LOCK
LOCK SWITCH
OFF OFF ON ON SUB SWITCH DOWN UP
OFF ON
OFF ON ON
OFF WINDOW SUB SWITCH
ON OFF
POWER WINDOW MAIN SWITCH
POWER WINDOW RELAY
RED WIRE
RIGHT FRONT POWER WINDOW MOTOR (CENTER OF FRONT PASSENGER'S DOOR)
RIGHT REAR POWER OFF ON WINDOW SUB DOWN SWITCH
RIGHT REAR POWER WINDOW MOTOR (CENTER OF RIGHT REAR DOOR)
UNLOCK
UP OFF IC
VIO WIRE
WHT WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Power windows circuit, except evolution without central door locking -> DOWN/ AUTO DOWN
