Mitsubishi Lancer X (2007-2010) c-317 13 6 c-312 8 7 16 12 c-313 7 Wiring diagrams
This page contains all the electrical diagrams for the component. c-317 13 6 c-312 8 7 16 12 c-313 7, in which he is found in the car Mitsubishi Lancer X (2007-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram c-317 13 6 c-312 8 7 16 12 c-313 7 (1 of 2)
& RECEIVER
21 20 8 7 W/O KOS W/ KOS
4 5 PNK C-301 WIRE
6 C-301 5 10 C-317
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BRN WIRE
BRN/WHT WIRE
C-312 15 9
C-313
C-317 13 6 C-312 8 7 16 12 C-313 7
CAN DRIVE CIRCUIT
CENTER PANEL UNIT
CIRCUIT INTERFACE
COMPUTER DATA LINES SYSTEM
ETACS-ECU (BEHIND LEFT END OF DASH)
FUSE 12
FUSE 8
FUSE 9
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY WIRE
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
JOINT CONNECTOR (CAN 1) (BEHIND INSTRUMENT CLUSTER)
JOINT CONNECTOR 3 (BEHIND INSTRUMENT CLUSTER)
JOINT CONNECTOR 6 (BEHIND RIGHT SIDE OF DASH)
KOS-ECU (W/ KOS) (UNDER LEFT SIDE OF DASH)
NCA WIRE
ORG/ WIRE
PNK WIRE
RECEIVER ANTENNA ASSEMBLY (LEFT SIDE OF LUGGAGE COMPT)
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RELAY ENERGIZED
THEFT-ALARM INDICATOR
VIO WIRE
W/ KOS
W/O KOS
WHT WIRE
WHT/BLU WIRE
WIRELESS CONTROL MODULE (W/O KOS) (ON STEERING COLUMN)
YEL WIRE
YEL/GRN WIRE
YEL/GRY WIRE
Go to component -> Forced entry circuit, evolution (1 of 2) -> C-317 13 6 C-312 8 7 16 12 C-313 7
