Mitsubishi Lancer X (2007-2010) auto switch (w/ automatic light) Wiring diagrams
This page contains all the electrical diagrams for the component. auto switch (w/ automatic light), in which he is found in the car Mitsubishi Lancer X (2007-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
auto switch (w/ automatic light) wiring diagram (1 of 2)
AUTO SWITCH (W/ AUTOMATIC LIGHT)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
COLUMN ECU
COLUMN SWITCH (LEFT SIDE OF STEERING COLUMN)
FOG LIGHTING SWITCH
HEAD LIGHTING SWITCH
HI LO
LEFT DAYTIME RUNNING LIGHT HEADLIGHT ASSEMBLY
LEFT FOG LIGHT
LEFT HEADLIGHT ASSEMBLY
LT GRN WIRE
NCA WIRE
ON OFF
ORG/ WIRE
RIGHT DAYTIME RUNNING LIGHT HEADLIGHT ASSEMBLY
RIGHT FOG LIGHT
RIGHT HEADLIGHT ASSEMBLY
TAIL LIGHTING SWITCH
VIO WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Headlights circuit, evolution with drl (2 of 2) -> AUTO SWITCH (W/ AUTOMATIC LIGHT)
auto switch (w/ automatic light) wiring diagram (2 of 2)
AUTO SWITCH (W/ AUTOMATIC LIGHT)
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU/RED WIRE
BRN WIRE
COLUMN ECU
COLUMN ECU (LEFT SIDE OF STEERING COLUMN)
DISCHARGE -ECU
FOG LIGHTING SWITCH
HEAD LIGHTING TAIL LIGHTING SWITCH SWITCH
HI LO
HI LO OFF
LEFT FOG LIGHT
LEFT HEADLIGHT ASSEMBLY
LT BLU WIRE
LT GRN WIRE
NCA WIRE
ON ON OFF OFF
ORG/ WIRE
PASS
PASSING SWITCH DIMMER SWITCH
PNK W/ DISCHARGE TYPE WIRE
PNK W/ HALOGEN TYPE WIRE
PNK WIRE
RIGHT FOG LIGHT
RIGHT HEADLIGHT ASSEMBLY
SOLENOID
VIO WIRE
YEL/BLU WIRE
Go to component -> Headlights circuit, evolution without drl (2 of 2) -> AUTO SWITCH (W/ AUTOMATIC LIGHT)
