Mitsubishi Lancer X (2007-2010) audio, video adapter Wiring diagrams

AUDIO, VIDEO ADAPTER BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE C-202 C-205 CAN TRANSCEIVER CIRCUIT CLOCK SPRING (C-205: TOP OF STEERING COLUMN) COMPUTER DATA LINES SYSTEM CRUISE CONTROL SYSTEM GRN WIRE GRN/WHT WIRE GRY WIRE GRY/RED WIRE HANG PICK UP UP ILL ILL ILL INTERFACE CIRCUIT MODE ORG/ WIRE PNK WIRE POWER SUPPLY RED WIRE RED/BLU WIRE SPEECH STEERING WHEEL AUDIO REMOTE CONTROL SWITCH STEERING WHEEL VOICE CONTROL SWITCH VIO WIRE VOL DN VOL UP CH DN CH UP WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/PNK WIRE

AUDIO, VIDEO ADAPTER BLK WIRE BLK/RED WIRE BLU WIRE BRN WIRE C-204 C-205 CAN TRANSCEIVER CIRCUIT CLOCK SPRING (IN STEERING COLUMN) COMBINATION METER COMPUTER DATA LINES SYSTEM GRN WIRE GRN/WHT WIRE GRY WIRE GRY/RED WIRE HANDS FREE MODULE (BEHIND RIGHT SIDE OF DASH) HANG PICK UP UP ILL ILL ILL INTERFACE CAN TRANSCEIVER CIRCUIT CIRCUIT INTERFACE CIRCUIT J/C C-01 (BEHIND LEFT SIDE OF DASH) J/C C-03 (BEHIND LEFT SIDE OF DASH) MICROPHONE UNIT (CENTER FRONT OF HEADLINER) MODE ORG/ WIRE PNK WIRE POWER SUPPLY RED WIRE RED/BLU WIRE RED/WHT WIRE SPEECH STEERING WHEEL AUDIO REMOTE CONTROL SWITCH STEERING WHEEL VOICE CONTROL SWITCH VIO WIRE VOL DN VOL UP CH DN CH UP WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/PNK WIRE

AUDIO, VIDEO ADAPTER BLK WIRE BLK/YEL WIRE BLU WIRE BRN/RED WIRE GRN WIRE GRY/BLU WIRE GRY/RED WIRE J/C 1 (BEHIND LEFT SIDE OF DASH) LEFT FRONT DOOR SPEAKER LEFT REAR DOOR SPEAKER LEFT TWEETER LT GRN WIRE NCA WIRE PNK WIRE RED/BLU WIRE RIGHT FRONT DOOR SPEAKER RIGHT REAR DOOR SPEAKER RIGHT TWEETER WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/RED WIRE

AUDIO, VIDEO ADAPTER BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE C-202 C-205 CAN TRANSCEIVER CIRCUIT CLOCK SPRING (C-205: TOP OF STEERING COLUMN) COMPUTER DATA LINES SYSTEM CRUISE CONTROL SYSTEM GRN WIRE GRN/WHT WIRE GRY WIRE GRY/RED WIRE HANG PICK UP UP ILL ILL ILL INTERFACE CIRCUIT MODE ORG/ WIRE PNK WIRE POWER SUPPLY RED WIRE RED/BLU WIRE SPEECH STEERING WHEEL AUDIO REMOTE CONTROL SWITCH STEERING WHEEL VOICE CONTROL SWITCH VIO WIRE VOL DN VOL UP CH DN CH UP WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/PNK WIRE

AUDIO, VIDEO ADAPTER BLK WIRE BLK/RED WIRE BLU WIRE BRN WIRE C-204 C-205 CAN TRANSCEIVER CIRCUIT CLOCK SPRING (IN STEERING COLUMN) COMBINATION METER COMPUTER DATA LINES SYSTEM GRN WIRE GRN/WHT WIRE GRY WIRE GRY/RED WIRE HANDS FREE MODULE (BEHIND RIGHT SIDE OF DASH) HANG PICK UP UP ILL ILL ILL INTERFACE CAN TRANSCEIVER CIRCUIT CIRCUIT INTERFACE CIRCUIT J/C C-01 (BEHIND LEFT SIDE OF DASH) J/C C-03 (BEHIND LEFT SIDE OF DASH) MICROPHONE UNIT (CENTER FRONT OF HEADLINER) MODE ORG/ WIRE PNK WIRE POWER SUPPLY RED WIRE RED/BLU WIRE RED/WHT WIRE SPEECH STEERING WHEEL AUDIO REMOTE CONTROL SWITCH STEERING WHEEL VOICE CONTROL SWITCH VIO WIRE VOL DN VOL UP CH DN CH UP WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/PNK WIRE

AUDIO, VIDEO ADAPTER BLK WIRE BLK/YEL WIRE BLU WIRE BRN/RED WIRE GRN WIRE GRY/BLU WIRE GRY/RED WIRE J/C 1 (BEHIND LEFT SIDE OF DASH) LEFT FRONT DOOR SPEAKER LEFT REAR DOOR SPEAKER LEFT TWEETER LT GRN WIRE NCA WIRE PNK WIRE RED/BLU WIRE RIGHT FRONT DOOR SPEAKER RIGHT REAR DOOR SPEAKER RIGHT TWEETER WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/RED WIRE
