Mitsubishi Lancer IX facelift (2005-2010) Radio circuit, except evolution without multi-communication system without amplifier

ANTENNA AMPLIFIER AUDIO SWITCH PANEL BLK WIRE BLK/RED WIRE BLK/YEL WIRE BLU WIRE BRN WIRE C-204 C-205 C-315 C-317 CENTER PANEL UNIT CH UP CH DN VOL UP CLOCK SPRING (C-205: IN STEERING COLUMN) COMPUTER DATA LINES SYSTEM CRUISE CONTROL SYSTEM FUSE 7 GRN/WHT WIRE GRY WIRE GRY/BLU WIRE GRY/RED WIRE HOT AT ALL TIMES ILL ILL ILL J/C 1 (BEHIND LEFT SIDE OF DASH) LCD PANEL (AUDIO) LEFT FRONT DOOR SPEAKER LEFT REAR DOOR SPEAKER LEFT TWEETER LT GRN WIRE MODE NAVIGATION SYSTEM NCA WIRE ORG/ WIRE PNK WIRE RADIO, CD PLAYER OR CD CHANGER RED WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT DOOR SPEAKER RIGHT REAR DOOR SPEAKER RIGHT TWEETER ROOF ANTENNA SATELLITE RADIO TUNER (IF EQUIPPED) STEERING WHEEL AUDIO REMOTE CONTROL SWITCH VIO WIRE VOL DN WHT WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE YEL/BLU WIRE YEL/RED WIRE
