Mitsubishi Lancer IX facelift (2005-2010) warning systems sound systems wiring diagram
This page shows the only wiring diagram for the component.warning systems sound systems, which is found in the car Mitsubishi Lancer IX facelift (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
warning systems sound systems wiring diagram (1 of 1)
ABS IND.
AIR CONDITIONING, SOUND, INTERIOR LIGHTS SYSTEMS
BEAM IND
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BRAKE IND
BRN WIRE
BRN/WHT WIRE
CAN TRANSCEIVER CIRCUIT
COMBINATION METER
COMPUTER DATA LINES SYSTEM
CONSOLE)
CRUISE IND
DRIVER'S SEAT BELT IND
DRL IND
FOG IND
FUEL LEVEL SENSOR
FUEL PUMP MODULE (TOP OF FUEL TANK)
FUEL TANK TEMPERATURE SENSOR
GENERATOR MALFUNCTION LIGHT IND
GRN WIRE
GRN/WHT WIRE
ILLUM
INTERFACE CIRCUIT
JOINT CONNECTOR 5 (BEHIND LEFT SIDE OF DASH)
LCD (CVT POSITION, CVT TEMPERATURE, CVT FAILURE)
LCD (EACH DOOR)
LCD (FUEL WARNING/OIL PRESSURE WARNING)
LCD (GENERATOR MALFUNCTION LIGHT)
LCD (KEY REMINDER)
LCD (KOS)
LCD (MALFUNCTION IND LIGHT) (SERVICE ENGINE SOON)
LCD (ODO/TRIP, FUEL GAUGE, TEMPERATURE GAUGE)
LCD (TIRE PRESSURE)
LED DRIVE CIRCUIT
LEFT TURN IND
LT BLU WIRE
LT GRN WIRE
MALFUNCTION IND LIGHT (SERVICE ENGINE SOON)
METER INFORMATION SWITCH
PARKING BRAKE SWITCH (UNDER CENTER
PNK WIRE
RED/WHT WIRE
RHEOSTAT
RIGHT TURN IND
SPEEDOMETER
SRS IND
TACHOMETER
TAIL IND
TONE ALARM
TRANSMISSIONS SYSTEM
VIO WIRE
WARNING SYSTEMS
WARNING SYSTEMS SOUND SYSTEMS
WHT/BLU WIRE
YEL WIRE
YEL/BLU WIRE
YEL/RED WIRE
Go to component -> Instrument cluster circuit, except evolution (1 of 2) -> WARNING SYSTEMS SOUND SYSTEMS
