Mitsubishi Lancer IX facelift (2005-2010) tone alarm Wiring diagrams
This page contains all the electrical diagrams for the component. tone alarm, in which he is found in the car Mitsubishi Lancer IX facelift (2005-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram tone alarm (1 of 5)
15 C-37
58 C-36 16
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
C-301
C-313
C-315
C-317
CAN DRIVE CIRCUIT
CENTER PANEL UNIT
CIRCUIT CAN DRIVE
CIRCUIT INTERFACE
COLUMN ECU
COLUMN ECU (LEFT SIDE OF STEERING COLUMN)
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DOOR
DRIVE CIRCUIT
DRIVER'S SEAT BELT IND
DRIVER'S SIDE SEAT BELT SWITCH (IN DRIVER'S SEAT BELT BUCKLE ASSEMBLY)
ETACS-ECU (BEHIND LEFT END OF DASH)
FUSE
GRN WIRE
GRY WIRE
HEAD
HOT AT ALL TIMES
HOT W/ IGNITION 1 RELAY ENERGIZED
INTERFACE CIRCUIT
KEY REMINDER
KEY REMINDER SWITCH
KOS-ECU (W/ KOS) (UNDER LEFT SIDE OF DASH)
LCD
LED
LEFT FRONT DOOR SWITCH (IN LEFT "B" PILLAR)
LIGHTING SWITCH
NCA WIRE
PASSENGER'S SEAT BELT IND
PASSENGER'S SEAT BELT SWITCH (IN FRONT PASSENGER'S SEAT BELT BUCKLE ASSEMBLY)
PNK WIRE
PUSH SWITCH
RED/BLK WIRE
RED/GRN WIRE
RED/YEL WIRE
SRS ECU (BEHIND LOWER CENTER OF DASH)
TAIL
TONE ALARM
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WHT/GRN WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/VIO WIRE
Go to component -> Chime circuit, evolution -> TONE ALARM
Wiring diagram tone alarm (2 of 5)
15 C-122
58 C-30 16
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BRN WIRE
C-301
C-313
C-315
C-317
CAN DRIVE CIRCUIT
CENTER PANEL UNIT
CIRCUIT CAN DRIVE
CIRCUIT INTERFACE
COLUMN ECU
COLUMN SWITCH-ECU (ON TOP OF STEERING COLUMN)
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DOOR
DRIVE CIRCUIT
DRIVER'S SEAT BELT IND
DRIVER'S SIDE SEAT BELT SWITCH (IN DRIVER'S SEAT BELT BUCKLE ASSEMBLY)
ETACS-ECU (ON REAR OF JUNCTION BLOCK, BEHIND LEFT END OF DASH)
FUSE
GRN WIRE
GRY WIRE
HEAD
HOT AT ALL TIMES
HOT W/ IGNITION 1 RELAY ENERGIZED
INTERFACE CIRCUIT
KEY REMINDER SWITCH
KOS-ECU (W/ KOS) (UNDER RIGHT SIDE OF DASH)
LED
LEFT FRONT DOOR SWITCH (IN LEFT "B" PILLAR)
LIGHTING SWITCH
NCA WIRE
PASSENGER'S SEAT BELT IND
PASSENGER'S SEAT BELT SWITCH (IN FRONT PASSENGER'S SEAT BELT BUCKLE ASSEMBLY)
PNK WIRE
PUSH SWITCH
RED/GRN WIRE
RED/WHT WIRE
REMINDER) (KEY LCD
SRS ECU (BEHIND LOWER CENTER OF DASH)
TAIL
TONE ALARM
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WHT/GRN WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/VIO WIRE
Go to component -> Chime circuit, except evolution -> TONE ALARM
Wiring diagram tone alarm (3 of 5)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
CAN TRANSCEIVER CIRCUIT
COMBINATION METER
ENGINE COMPARTMENT FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPT) HORN RELAY
FUSE 4
FUSE 9
GRN WIRE
GRY WIRE
HOOD SWITCH (CENTER FRONT OF ENGINE COMPT)
HORNS SYSTEM
HOT AT ALL TIMES
LCD (SECURITY)
LEFT FRONT DOOR SWITCH (IN LEFT "B" PILLAR)
LEFT REAR DOOR SWITCH (IN LEFT "C" PILLAR)
NCA WIRE
PNK WIRE
RED WIRE
RED/WHT WIRE
RIGHT FRONT DOOR SWITCH (IN RIGHT "B" PILLAR)
RIGHT REAR DOOR SWITCH (IN RIGHT "C" PILLAR)
THEFT-ALARM HORN (RIGHT REAR OF ENGINE COMPT)
THEFT-ALARM HORN RELAY (IN ENGINE COMPT RELAY BOX)
TONE ALARM
YEL WIRE
Go to component -> Forced entry circuit, evolution (2 of 2) -> TONE ALARM
Wiring diagram tone alarm (4 of 5)
ABS IND.
AIR CONDITIONING, SOUND, INTERIOR LIGHTS SYSTEMS
BEAM IND
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BRAKE IND
BRN WIRE
BRN/WHT WIRE
CAN TRANSCEIVER CIRCUIT
COMBINATION METER
COMPUTER DATA LINES SYSTEM
CONSOLE)
CRUISE IND
DRIVER'S SEAT BELT IND
FOG IND
FUEL LEVEL SENSOR
FUEL LEVEL SENSOR (SUB)
FUEL PUMP MODULE (TOP OF FUEL TANK)
FUEL TANK TEMPERATURE SENSOR
GENERATOR MALFUNCTION LIGHT IND
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
ILLUM
INTERFACE CIRCUIT
JOINT CONNECTOR 3 (BEHIND INSTRUMENT CLUSTER)
JOINT CONNECTOR 5 (BASE OF LEFT "B" PILLAR)
LCD (EACH DOOR)
LCD (ENGINE COOLANT TEMPERATURE)
LCD (FUEL WARNING, OIL, BRAKE)
LCD (GENERATOR MALFUNCTION LIGHT)
LCD (KEY REMINDER)
LCD (KOS)
LCD (MALFUNCTION IND LIGHT) (SERVICE ENGINE SOON)
LCD (SECURITY)
LCD (SHIFT POSITION, NORMAL, SPORT, S-SPORT)
LCD (TIRE PRESSURE)
LED DRIVE CIRCUIT
LEFT TURN IND
LT BLU WIRE
LT GRN WIRE
MALFUNCTION IND LIGHT (SERVICE ENGINE SOON)
METER INFORMATION SWITCH
PARKING BRAKE SWITCH (UNDER CENTER
PNK WIRE
RADIO, CD PLAYER
RED/WHT WIRE
RHEOSTAT
RIGHT TURN IND
SPEEDOMETER
SRS IND
TACHOMETER
TAIL IND
TONE ALARM
TRANSMISSIONS SYSTEM
WARNING SYSTEMS
WHT/BLK WIRE
WHT/BLU WIRE
YEL/BLU WIRE
YEL/RED WIRE
Go to component -> Instrument cluster circuit, evolution (1 of 2) -> TONE ALARM
Wiring diagram tone alarm (5 of 5)
ABS IND.
AIR CONDITIONING, SOUND, INTERIOR LIGHTS SYSTEMS
BEAM IND
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BRAKE IND
BRN WIRE
BRN/WHT WIRE
CAN TRANSCEIVER CIRCUIT
COMBINATION METER
COMPUTER DATA LINES SYSTEM
CONSOLE)
CRUISE IND
DRIVER'S SEAT BELT IND
DRL IND
FOG IND
FUEL LEVEL SENSOR
FUEL PUMP MODULE (TOP OF FUEL TANK)
FUEL TANK TEMPERATURE SENSOR
GENERATOR MALFUNCTION LIGHT IND
GRN WIRE
GRN/WHT WIRE
ILLUM
INTERFACE CIRCUIT
JOINT CONNECTOR 5 (BEHIND LEFT SIDE OF DASH)
LCD (CVT POSITION, CVT TEMPERATURE, CVT FAILURE)
LCD (EACH DOOR)
LCD (FUEL WARNING/OIL PRESSURE WARNING)
LCD (GENERATOR MALFUNCTION LIGHT)
LCD (KEY REMINDER)
LCD (KOS)
LCD (MALFUNCTION IND LIGHT) (SERVICE ENGINE SOON)
LCD (ODO/TRIP, FUEL GAUGE, TEMPERATURE GAUGE)
LCD (TIRE PRESSURE)
LED DRIVE CIRCUIT
LEFT TURN IND
LT BLU WIRE
LT GRN WIRE
MALFUNCTION IND LIGHT (SERVICE ENGINE SOON)
METER INFORMATION SWITCH
PARKING BRAKE SWITCH (UNDER CENTER
PNK WIRE
RED/WHT WIRE
RHEOSTAT
RIGHT TURN IND
SPEEDOMETER
SRS IND
TACHOMETER
TAIL IND
TONE ALARM
TRANSMISSIONS SYSTEM
VIO WIRE
WARNING SYSTEMS
WARNING SYSTEMS SOUND SYSTEMS
WHT/BLU WIRE
YEL WIRE
YEL/BLU WIRE
YEL/RED WIRE
Go to component -> Instrument cluster circuit, except evolution (1 of 2) -> TONE ALARM
