Mitsubishi Lancer IX facelift (2005-2010) shift lock control relay Wiring diagram
This page shows the only wiring diagram for the component.shift lock control relay, which is found in the car Mitsubishi Lancer IX facelift (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram shift lock control relay (1 of 1)
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
C-304
C-317
ETACS-ECU (ON REAR OF JUNCTION BLOCK, BEHIND LEFT END OF DASH) RELAY
FUSE
HOT AT ALL TIMES
HOT IN ON OR START
P RANGE DETECTION SWITCH
RED WIRE
SHIFT LOCK CONTROL RELAY
SHIFT LOCK SOLENOID
SHIFT SWITCH ASSEMBLY
STOPLIGHT SWITCH (UNDER LEFT SIDE OF DASH)
Go to component -> Shift interlock circuit, except evolution -> SHIFT LOCK CONTROL RELAY
