Mitsubishi Lancer IX facelift (2005-2010) low low side side switch switch Wiring diagram
This page shows the only wiring diagram for the component.low low side side switch switch, which is found in the car Mitsubishi Lancer IX facelift (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram low low side side switch switch (1 of 1)
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
C-315
C-317
CAN TRANSCEIVER CIRCUIT
COMBINATION METER
COMPUTER DATA LINES SYSTEM
FUSE 12
FUSE 16
GRN WIRE
GRY WIRE
GRY/BLU WIRE
HOT AT ALL TIMES ETACS -ECU FUSE 9 (BEHIND LEFT END OF DASH)
HOT W/
HOT W/ ACC RELAY 2 ENERGIZED
ILL
INTERFACE CIRCUIT
LCD (SHIFT POSITION, NORMAL, SPORT, S-SPORT)
LOW LOW SIDE SIDE SWITCH SWITCH
LOW SIDE SWITCH
MANUAL
MODE
NCA WIRE
PADDLE SHIFT SWITCH
PNK WIRE
RED/GRN WIRE
SHIFT LEVER POSITION INDICATOR PANEL
SHIFT LEVER POSITION SENSOR (P,R,N,D,M,+,-)
SHIFT LEVER)
TRANSAXLE ASSEMBLY)
TWIN CLUTCH SPORT SHIFT TRANSAXLE CONTROL MODULE SWITCH
WHT/BLU WIRE
YEL WIRE
Go to component -> Transmission circuit, evolution -> LOW LOW SIDE SIDE SWITCH SWITCH
