Mitsubishi Lancer IX facelift (2005-2010) left headlight assembly, right headlight assembly, shift lever, asc-ecu Wiring diagram
This page shows the only wiring diagram for the component.left headlight assembly, right headlight assembly, shift lever, asc-ecu, which is found in the car Mitsubishi Lancer IX facelift (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left headlight assembly, right headlight assembly, shift lever, asc-ecu (1 of 1)
BATTERY
BLK WIRE
COMBINATION METER
ENGINE CONTROL MODULE
ENGINE CONTROL MODULE, CONDENSER FAN MOTOR, FAN CONTROL RELAY
FUEL PUMP MODULE
LEFT BACKUP LIGHT RIGHT BACKUP LIGHT
LEFT HEADLIGHT ASSEMBLY, RIGHT HEADLIGHT ASSEMBLY, SHIFT LEVER, ASC-ECU
RED WIRE
S-AWC-ECU
SRS ECU
TRUNK LID LATCH
W/O KOS
WHT WIRE
YEL WIRE
Go to component -> Ground distribution circuit, evolution (2 of 2) -> LEFT HEADLIGHT ASSEMBLY, RIGHT HEADLIGHT ASSEMBLY, SHIFT LEVER, ASC-ECU
