Mitsubishi Lancer IX facelift (2005-2010) grn Wiring diagrams

B-108 B-09 B-109 B-10 60 61 62 BATTERY BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BRN WIRE C-317 CAN TRANSCEIVER GENERATOR MALFUNCTION LIGHT CIRCUIT COMBINATION METER COMPUTER DATA LINES SYSTEM ENGINE COMPARTMENT FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPT) EVOLUTION EXCEPT EVOLUTION FUSE 5 FUSIBLE LINK 33 FUSIBLE LINK 36 FUSIBLE LINK BOX (EXCEPT EVOLUTION: NEXT TO BATTERY) (EVOLUTION: NEAR RELAY BOX) GENERATOR GRN WIRE GRN/RED WIRE LCD (GENERATOR MALFUNCTION LIGHT) LED DRIVE CPU CIRCUIT NCA WIRE PNK WIRE RED WIRE RED/GRN WIRE RELAY ENERGIZED ETACS-ECU (BEHIND FUSE 12 LEFT END OF DASH) STARTING CIRCUIT WHT WIRE WHT/RED WIRE YEL WIRE

AUDIO, VIDEO ADAPTER BLK WIRE BLK/RED WIRE BLU WIRE BRN WIRE C-204 C-205 CAN TRANSCEIVER CIRCUIT CLOCK SPRING (IN STEERING COLUMN) COMBINATION METER COMPUTER DATA LINES SYSTEM GRN WIRE GRN/WHT WIRE GRY WIRE GRY/RED WIRE HANDS FREE MODULE (BEHIND RIGHT SIDE OF DASH) HANG PICK UP UP ILL ILL ILL INTERFACE CAN TRANSCEIVER CIRCUIT CIRCUIT INTERFACE CIRCUIT J/C C-01 (BEHIND LEFT SIDE OF DASH) J/C C-03 (BEHIND LEFT SIDE OF DASH) MICROPHONE UNIT (CENTER FRONT OF HEADLINER) MODE ORG/ WIRE PNK WIRE POWER SUPPLY RED WIRE RED/BLU WIRE RED/WHT WIRE SPEECH STEERING WHEEL AUDIO REMOTE CONTROL SWITCH STEERING WHEEL VOICE CONTROL SWITCH VIO WIRE VOL DN VOL UP CH DN CH UP WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/PNK WIRE

AUDIO AMPLIFIER (UNDER DRIVER'S SEAT) BLK WIRE BLK/RED WIRE BLK/YEL WIRE BLU WIRE BRN WIRE C-105 ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPT) FUSE 31 GRN WIRE GRY WIRE GRY/BLU WIRE GRY/RED WIRE HOT AT ALL TIMES LEFT FRONT DOOR SPEAKER LEFT REAR DOOR SPEAKER LEFT TWEETER LT GRN WIRE NCA WIRE PNK WIRE RED WIRE RED/BLU WIRE RIGHT FRONT DOOR SPEAKER RIGHT REAR DOOR SPEAKER RIGHT TWEETER SUB-WOOFER WHT WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE

17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 C-14 21 C-13 47 46 45 44 43 42 41 C-12 87 86 85 84 83 82 81 C-11 A/T ANTENNA AMPLIFIER AUDIO VISUAL NAVIGATION UNIT BACKUP LIGHT SWITCH (ON BLK WIRE BLK/PNK WIRE BLK/RED WIRE BLU WIRE BLU/GRN WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE C-301 C-304 C-311 C-313 C-315 C-317 COMPUTER DATA LINES SYSTEM ETACS-ECU (ON REAR OF JUNCTION BLOCK, BEHIND LEFT END OF DASH) FUSE 16 FUSE 7 FUSE 9 FUSE FUSE 18 18 GPS ANTENNA GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/WHT WIRE GRY/BLU WIRE GRY/RED WIRE HOT AT ALL TIMES HOT W/ ACC RELAY 2 ENERGIZED INTERFACE CIRCUIT J/C C-03 (BEHIND LEFT SIDE OF DASH) JUNCTION CONNECTOR 1 (BEHIND LEFT SIDE OF DASH) JUNCTION CONNECTOR 4 (BEHIND LEFT KICK PANEL) LT BLU WIRE LT GRN WIRE M/T NCA WIRE ORG/ WIRE PNK WIRE RED WIRE RED/ WHT WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RELAY ENERGIZED ROOF ANTENNA SATELLITE RADIO TUNER (VEHICLES W/ SATELLITE RADIO TUNER) TRANSMISSION TRANSMISSION RANGE SWITCH (TOP OF TRANSMISSION) VIO WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/PNK WIRE YEL/VIO WIRE

BLK WIRE BLK/RED WIRE BLU WIRE BRN WIRE C-204 C-205 CAN TRANSCEIVER CIRCUIT CLOCK SPRING (IN STEERING COLUMN) COMBINATION METER COMPUTER DATA LINES SYSTEM GRN WIRE GRN/WHT WIRE GRY WIRE GRY/BLU WIRE GRY/RED WIRE HANDS FREE MODULE (BEHIND RIGHT SIDE OF DASH) HANG PICK UP UP ILL ILL ILL INTERFACE CAN TRANSCEIVER CIRCUIT CIRCUIT INTERFACE CIRCUIT J/C C-01 (BEHIND LEFT SIDE OF DASH) J/C C-03 (BEHIND LEFT SIDE OF DASH) MICROPHONE UNIT (CENTER FRONT OF HEADLINER) MODE ORG/ WIRE PNK WIRE POWER SUPPLY RED WIRE RED/BLU WIRE RED/WHT WIRE SPEECH STEERING WHEEL AUDIO REMOTE CONTROL SWITCH STEERING WHEEL VOICE CONTROL SWITCH VIO WIRE VOL DN VOL UP CH DN CH UP WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/PNK WIRE

AUDIO, VIDEO ADAPTER BLK WIRE BLK/YEL WIRE BLU WIRE BRN/RED WIRE GRN WIRE GRY/BLU WIRE GRY/RED WIRE J/C 1 (BEHIND LEFT SIDE OF DASH) LEFT FRONT DOOR SPEAKER LEFT REAR DOOR SPEAKER LEFT TWEETER LT GRN WIRE NCA WIRE PNK WIRE RED/BLU WIRE RIGHT FRONT DOOR SPEAKER RIGHT REAR DOOR SPEAKER RIGHT TWEETER WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/RED WIRE

10 16 PNK WIRE 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 C-106 PNK WIRE 40 39 38 37 36 35 34 33 32 31 30 29 28 27 26 25 24 23 22 21 C-104 64 63 62 61 60 59 58 57 56 55 54 53 52 51 50 49 48 47 46 45 44 43 42 41 C-102 ANTENNA AMPLIFIER AUDIO SWITCH PANEL BLK WIRE BLU WIRE BRN WIRE C-315 C-317 CENTER PANEL UNIT COMPUTER DATA LINES SYSTEM ETACS-ECU (ON REAR OF JUNCTION BLOCK, BEHIND LEFT END OF DASH) FUSE 16 FUSE 7 GRN WIRE GRN/WHT WIRE HOT AT ALL TIMES HOT W/ ACC RELAY 2 ENERGIZED J/C 1 (BEHIND LEFT SIDE OF DASH) LCD PANEL (AUDIO) LT GRN WIRE NAVIGATION SYSTEM NCA WIRE ORG/ WIRE PNK WIRE RADIO, CD PLAYER OR CD CHANGER RED WIRE RED/WHT WIRE RED/YEL WIRE ROOF ANTENNA SATELLITE RADIO TUNER (IF EQUIPPED) WHT WIRE YEL WIRE

AUDIO AMPLIFIER (UNDER DRIVER'S SEAT) BLK WIRE BLK/RED WIRE BLK/YEL WIRE BLU WIRE BRN WIRE C-204 C-205 CH DN CH UP VOL UP CLOCK SPRING (C-205: IN STEERING COLUMN) CRUISE CONTROL SYSTEM ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPT) FUSE 31 GRN WIRE GRN/WHT WIRE GRY WIRE GRY/BLU WIRE GRY/RED WIRE HOT AT ALL TIMES ILL ILL ILL LEFT FRONT DOOR SPEAKER LEFT REAR DOOR SPEAKER LEFT TWEETER LT GRN WIRE MODE NCA WIRE PNK WIRE RED WIRE RIGHT FRONT DOOR SPEAKER RIGHT REAR DOOR SPEAKER RIGHT TWEETER STEERING WHEEL AUDIO REMOTE CONTROL SWITCH SUB-WOOFER VIO WIRE VOL DN WHT WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE YEL/BLU WIRE YEL/RED WIRE

A/T B-09 B-10 BATTERY BLK WIRE BLK/RED WIRE BLK/YEL WIRE BLU/RED WIRE C-304 C-309 C-315 C-317 CLUTCH INTERLOCK SWITCH (TOP OF CLUTCH PEDAL ASSEMBLY) COMPUTER DATA LINES SYSTEM ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPT) ENGINE CONTROL MODULE (NEAR RELAY BOX) ETACS-ECU (BEHIND LEFT END OF DASH) FUSE 14 FUSIBLE LINK 24 FUSIBLE LINK 34 FUSIBLE LINK 36 GRN WIRE GRN/WHT WIRE IGNITION SWITCH JUNCTION CONNECTOR 7 (BEHIND LEFT SIDE OF DASH) LOCK LT GRN WIRE M/T M/T A/T ORG/ WIRE POSITION SWITCH (N) POSITION SWITCH (P) RUN WIRE SHIFT LEVER) STARTER STARTER RELAY (IN ENGINE COMPT RELAY BOX) WHT WIRE YEL WIRE

A/T A/T M/T B-109 BATTERY BLK WIRE BLK/RED WIRE BLK/YEL WIRE C-304 C-309 C-315 C-317 CLUTCH INTERLOCK SWITCH (UNDER LEFT SIDE OF DASH) STARTER COMPUTER DATA LINES SYSTEM ENGINE COMPARTMENT FUSE, RELAY BOX (LEFT SIDE OF ENGINE COMPT) ENGINE CONTROL MODULE (LEFT REAR OF ENGINE COMPT) ENGINE CONTROLS SYSTEM ETACS-ECU (ON REAR OF JUNCTION BLOCK, BEHIND LEFT END OF DASH) FUSE 14 FUSIBLE LINK 24 FUSIBLE LINK 34 FUSIBLE LINK 36 GRN WIRE GRN/RED WIRE IGNITION SWITCH LOCK LT GRN WIRE M/T NCA WIRE ORG/ WIRE PNK WIRE RED WIRE RED/WHT WIRE RUN WIRE STARTER RELAY (M/T: ON UNDERHOOD FUSE/RELAY BLOCK) TRANSMISSION RANGE SWITCH (TOP OF TRANSMISSION) WHT WIRE YEL WIRE
