Mitsubishi Lancer IX facelift (2005-2010) front power window sub switch Wiring diagrams
This page contains all the electrical diagrams for the component. front power window sub switch, in which he is found in the car Mitsubishi Lancer IX facelift (2005-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram front power window sub switch (1 of 3)
15 C-315
2 5 C-315 10 C-301 9 6 C-311 13 C-315 10 5 C-317 PNK WIRE
2 C-301
22 C-301
4 E-08
6 C-301
8 7 16 12 C-313
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
CAN DRIVE CIRCUIT
COMPUTER DATA LINES SYSTEM
DOOR LOCK RELAY
DRIVER'S DOOR UNLOCK RELAY
ETACS-ECU (BEHIND LEFT END OF DASH)
FRONT POWER WINDOW SUB SWITCH
FUSE 12
FUSE 6
FUSE 8
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/
INTERFACE CIRCUIT
JOINT CONNECTOR 1 (BEHIND INSTRUMENT CLUSTER)
JOINT CONNECTOR 3 (BEHIND INSTRUMENT CLUSTER)
JOINT CONNECTOR 3 (BEHIND INSTRUMENT PANEL)
LEFT FRONT DOOR SWITCH (IN LEFT "B" PILLAR)
LEFT REAR DOOR SWITCH (IN LEFT "C" PILLAR)
LT GRN WIRE
PASSENGER'S DOOR UNLOCK RELAY
PNK WIRE
POWER WINDOW MAIN SWITCH
RED WIRE
RED/BLK WIRE
RED/YEL WIRE
RIGHT FRONT DOOR SWITCH (IN RIGHT "B" PILLAR)
RIGHT REAR DOOR SWITCH (IN RIGHT "C" PILLAR)
WHT/BLU WIRE
YEL WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Power door locks circuit, evolution with keyless entry (1 of 3) -> FRONT POWER WINDOW SUB SWITCH
Wiring diagram front power window sub switch (2 of 3)
& RECEIVER
15 C-315
2 C-301 8 7 16 12 C-313 10 5 C-317 4
22 C-301
4 E-08
5 C-301 PNK WIRE
6 2 5 C-315 10 C-301 9 6 C-311 13
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
BRN/WHT WIRE
CAN DRIVE CIRCUIT
COMPUTER DATA LINES SYSTEM
DOOR LOCK RELAY
DRIVER'S DOOR UNLOCK RELAY
ETACS-ECU (BEHIND LEFT END OF DASH)
FRONT POWER WINDOW SUB SWITCH
FUSE 12
FUSE 8 FUSE 6
GRN WIRE
GRN/RED WIRE
GRY WIRE
HOT AT ALL TIMES
INTERFACE CIRCUIT
JOINT CONNECTOR 1 (BEHIND INSTRUMENT CLUSTER)
JOINT CONNECTOR 3 (BEHIND INSTRUMENT CLUSTER)
JOINT CONNECTOR 4 (BEHIND LEFT KICK PANEL)
JOINT CONNECTOR 6 (BEHIND RIGHT SIDE OF DASH)
KEY REMINDER SWITCH
LEFT FRONT DOOR SWITCH (IN LEFT "B" PILLAR)
LEFT REAR DOOR SWITCH (IN LEFT "C" PILLAR)
LT GRN WIRE
PASSENGER'S DOOR UNLOCK RELAY
PNK WIRE
POWER WINDOW MAIN SWITCH
RECEIVER ANTENNA ASSEMBLY (LEFT SIDE OF LUGGAGE COMPT)
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY ENERGIZED
RIGHT FRONT DOOR SWITCH (IN RIGHT "B" PILLAR)
RIGHT REAR DOOR SWITCH (IN RIGHT "C" PILLAR)
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
WIRELESS CONTROL MODULE (ON STEERING COLUMN)
YEL WIRE
YEL/GRY WIRE
YEL/RED WIRE
Go to component -> Power door locks circuit, evolution without keyless entry -> FRONT POWER WINDOW SUB SWITCH
Wiring diagram front power window sub switch (3 of 3)
1 C-311 5 8 7 16 12 C-313
15 C-315
2 5 C-315 10 C-301 9 6 C-311 13 C-315 10 5 C-317 PNK WIRE
2 C-301
22 C-301
4 E-08
5 C-301
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
CAN DRIVE CIRCUIT
COMPUTER DATA LINES SYSTEM
DOOR LOCK RELAY
DRIVER'S DOOR UNLOCK RELAY
ETACS-ECU (ON REAR OF JUNCTION BLOCK, BEHIND LEFT END OF DASH)
FRONT POWER WINDOW SUB SWITCH
FUSE 12
FUSE 6
FUSE 8
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INTERFACE CIRCUIT
JOINT CONNECTOR 1 (BEHIND LEFT SIDE OF DASH)
JOINT CONNECTOR 3 (BEHIND LEFT SIDE OF DASH)
LEFT FRONT DOOR SWITCH (IN LEFT "B" PILLAR)
LEFT REAR DOOR SWITCH (IN LEFT "C" PILLAR)
LT GRN WIRE
PASSENGER'S DOOR UNLOCK RELAY
PNK WIRE
POWER WINDOW MAIN SWITCH
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
RELAY ENERGIZED
RIGHT FRONT DOOR SWITCH (IN RIGHT "B" PILLAR)
RIGHT REAR DOOR SWITCH (IN RIGHT "C" PILLAR)
TRUNK LID LOCK ACTUATOR (CENTER REAR OF TRUNK LID)
TRUNK LID LOCK RELAY
VIO WIRE
WHT WIRE
WHT/RED WIRE
YEL WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Power door locks circuit, except evolution with keyless entry (1 of 3) -> FRONT POWER WINDOW SUB SWITCH
