Mitsubishi Lancer IX facelift (2005-2010) ch dn ch up vol up Wiring diagram
This page shows the only wiring diagram for the component.ch dn ch up vol up, which is found in the car Mitsubishi Lancer IX facelift (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ch dn ch up vol up (1 of 1)
AUDIO AMPLIFIER (UNDER DRIVER'S SEAT)
BLK WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
C-204
C-205
CH DN CH UP VOL UP
CLOCK SPRING (C-205: IN STEERING COLUMN)
CRUISE CONTROL SYSTEM
ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPT)
FUSE 31
GRN WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLU WIRE
GRY/RED WIRE
HOT AT ALL TIMES
ILL
ILL ILL
LEFT FRONT DOOR SPEAKER
LEFT REAR DOOR SPEAKER
LEFT TWEETER
LT GRN WIRE
MODE
NCA WIRE
PNK WIRE
RED WIRE
RIGHT FRONT DOOR SPEAKER
RIGHT REAR DOOR SPEAKER
RIGHT TWEETER
STEERING WHEEL AUDIO REMOTE CONTROL SWITCH
SUB-WOOFER
VIO WIRE
VOL DN
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLU WIRE
YEL/RED WIRE
Go to component -> Radio circuit, except evolution without multi-communication system with amplifier (2 of 2) -> CH DN CH UP VOL UP
