Mitsubishi Lancer IX facelift (2005-2010) abs ecu, transaxle control module Wiring diagram
This page shows the only wiring diagram for the component.abs ecu, transaxle control module, which is found in the car Mitsubishi Lancer IX facelift (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram abs ecu, transaxle control module (1 of 1)
ABS ECU, TRANSAXLE CONTROL MODULE
BATTERY
BLK WIRE
BLK/YEL WIRE
COMBINATION METER
DATA LINK CONNECTOR, ETACS ECU
DRIVER'S SIDE SEAT BELT SWITCH,
ENGINE CONTROL MODULE
ENGINE CONTROL MODULE, CONDENSER FAN MOTOR, FAN CONTROL RELAY
FRONT DOME LIGHT, SUNROOF MOTOR ASSEMBLY
FUEL PUMP MODULE
IGNITION COIL 1
IGNITION COIL 2 IGNITION COIL 3 IGNITION COIL 4
LEFT FRONT SEAT ASSEMBLY, RIGHT FRONT SEAT ASSEMBLY
REAR OF ENGINE COMPT)
RIGHT HEATED SEAT, LEFT HEATED SEAT, AUDIO AMPLIFIER
SRS ECU
W/ KOS
W/O KOS
Go to component -> Ground distribution circuit, except evolution -> ABS ECU, TRANSAXLE CONTROL MODULE
