Mitsubishi Lancer IX (2000-2007) 2.0l, a/t circuit

14 7 DATA LINK CONNECTOR (BELOW LEFT SIDE OF DASH) 41 44 45 46 47 49 50 57 66 C-118 74 A/T CONTROL RELAY (ON ENGINE COMPT RELAY BOX) A/T CONTROL SOLENOID VALVE ASSEMBLY (ON REAR OF TRANSAXLE) BLK WIRE BLK/RED WIRE BLK/YEL WIRE BLU WIRE BLU/YEL WIRE BRN WIRE BRN/GRN WIRE C-114 C-120 C-210 CRANKSHAFT POSITION SENSOR (ON LOWER FRONT OF ENGINE) ENGINE COMPARTMENT RELAY BOX (ON LEFT SIDE OF ENGINE COMPT) ENGINE CONTROLS SYSTEM ENGINE COOLANT TEMPERATURE SENSOR (ON REAR OF CYLINDER HEAD) FUSE 10 FUSE 14 FUSE 3 FUSE 8 GRN WIRE GRN/RED WIRE GRY WIRE HOT AT ALL TIMES HOT IN RUN OR START INPUT SHAFT SPEED SENSOR (ON TOP CENTER OF TRANSAXLE) J/C 2 (BEHIND INSTRUMENT CLUSTER) J/C 5 (BEHIND INSTRUMENT CLUSTER J/C 6 (BEHIND LOWER CENTER OF DASH) JUNCTION BLOCK, BEHIND LEFT END OF DASH) LOW, REVERSE LT GRN WIRE MFI RELAY (ON ENGINE COMPARTMENT RELAY BOX) ORG/ WIRE OUTPUT SHAFT SPEED SENSOR (ON TOP RIGHT OF TRANSAXLE) PNK WIRE POWERTRAIN CONTROL MODULE (BEHIND GLOVE BOX) RED WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE STARTING/ CHARGING SYSTEM STOP LIGHT SWITCH (ABOVE BRAKE PEDAL, ON BRACKET) THROTTLE POSITION SENSOR (ON THROTTLE BODY) TORQUE CONVERTER CONTROL OVER DRIVE SECOND TRANSMISSION RANGE SWITCH (LEFT FRONT OF ENGINE COMPT) UNDER DRIVE A/T OIL TEMP VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE YEL/WHT WIRE
