Manual a/c circuit, except evolution for Mitsubishi Lancer IX (2000-2007)

A/C-ECU (BEHIND CENTER OF DASH, BELOW RADIO) AIR THERMO SENSOR (BEHIND RIGHT CENTER OF OF DASH, ON HVAC UNIT) BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLOWER MOTOR (BEHIND RIGHT END OF DASH) BLOWER RELAY BLOWER SWITCH BLU WIRE BLU/BLK WIRE BRN WIRE CONDENSER FAN MOTOR (MOUNTED ON REAR OF RADIATOR) DEFOGGER SYSTEM FAN CONTROL MODULE (ON FAN SHROUD, AT LEFT FRONT OF ENGINE COMPARTMENT) FUSE 19 FUSE 5 GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HEATER CONTROL PANEL, ILLUMINATION HOT AT ALL TIMES HOT IN ON INLET SIDE JOINT CONNECTOR 2 (BEHIND INSTRUMENT CLUSTER) JOINT CONNECTOR 3 (BEHIND RIGHT SIDE OF DASH) JUNCTION BLOCK, BEHIND LEFT END OF DASH) LT GRN WIRE NCA WIRE OFF LO 4 5 ML MH OUTLET SIDE RADIATOR FAN MOTOR RED WIRE RED/YEL WIRE RESISTOR (BEHIND RIGHT SIDE OF DASH, ON HVAC UNIT) WHT WIRE WHT/BLK WIRE YEL WIRE YEL/RED WIRE

2.0L A/T 2.0L M/T 2.4L ENGINE CONTROLS 2.4L M/T 2.4L A/T A/C COMPRESSOR ASSEMBLY A/C COMPRESSOR CLUTCH A/C COMPRESSOR CLUTCH RELAY BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/GRN WIRE BLU/RED WIRE DUAL PRESSURE SWITCH (ON RIGHT FRONT OF ENGINE COMPT) ENGINE COMPARTMENT RELAY BOX (ON LEFT SIDE OF ENGINE COMPARTMENT) ENGINE COMPARTMENT RELAY BOX (ON LEFT SIDE OF ENGINE COMPT) ENGINE CONTROLS SYSTEM ENGINE COOLANT TEMPERATURE SENSOR (ON REAR OF CYLINDER HEAD) EXTERIOR LIGHTS FAN CONTROL RELAY FUSE 20 FUSE 8 FUSE 9 FUSIBLE LINK 2 GRN WIRE GRN/WHT WIRE GRN/YEL WIRE HIGH PRESSURE SIDE ON-OFF: 3138 KPA OFF-ON: 2550 KPA HOT AT ALL TIMES HOT W/ TAILLIGHT RELAY ENERGIZED JOINT CONNECTOR 1 (BEHIND CENTER OF DASH) JOINT CONNECTOR 6 (BEHIND LOWER CENTER OF DASH) LOW PRESSURE SIDE ON-OFF: 196 KPA OFF-ON: 221 KPA MFI RELAY NCA WIRE OFF ON OFF PNK WIRE POWERTRAIN CONTROL MODULE (A/T) ENGINE CONTROL MODULE RED WIRE RED/YEL WIRE SYSTEM WHT WIRE WHT/BLK WIRE YEL WIRE YEL/WHT WIRE
