Mitsubishi Lancer IX (2000-2007) starting circuit Wiring diagrams
This page contains all the electrical diagrams for the component. starting circuit, in which he is found in the car Mitsubishi Lancer IX (2000-2007). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
starting circuit wiring diagram (1 of 2)
BATTERY
BLK/BLU WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/WHT WIRE
COMBINATION METER
DEDICATED FUSE 12
ENGINE COMP- ARTMENT RELAY BOX (ON LEFT SIDE OF ENGINE COMPT)
ENGINE CONTROL MODULE (BEHIND GLOVE BOX)
FUSE 2
FUSIBLE LINK 26
FUSIBLE LINK 4
GENERATOR 4 2 FR
GENERATOR MALFUNCTION LIGHT
IGNITION SWITCH
JOINT CONNECTOR 4
JUNCTION BLOCK, BEHIND LEFT END OF DASH)
LOCK
NCA WIRE
ON OFF
ORG/ WIRE
RED WIRE
STARTING CIRCUIT
WHT WIRE
WHT/RED WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Charging circuit, evolution -> STARTING CIRCUIT
starting circuit wiring diagram (2 of 2)
41 54 86 86 2.0L M/T 2.0L A/T 2.4L M/T 2.4L A/T 33 8 45 45
BATTERY
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/WHT WIRE
CHARGE INDICATOR
COMB- INATION METER
DEDICATED FUSE 12
ENGINE COMP- ARTMENT RELAY BOX (ON LEFT SIDE OF ENGINE COMPT)
ENGINE CONTROL MODULE (M/T)
FUSIBLE LINK 26
FUSIBLE LINK 4
GENERATOR 4 2 FR
IGNITION SWITCH
JOINT CONNECTOR 5 (BEHIND INSTRUMENT CLUSTER)
JUNCTION BLOCK (BEHIND LEFT END OF DASH) MULTI- PURPOSE FUSE 2
LOCK
NCA WIRE
ON OFF
ORG/ WIRE
POWERTRAIN CONTROL MODULE (A/T) (BEHIND GLOVE BOX)
RED WIRE
STARTING CIRCUIT
WHT WIRE
WHT/RED WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Charging circuit, except evolution -> STARTING CIRCUIT
