Mitsubishi Lancer IX (2000-2007) power window sub switch door lock switch Wiring diagram
This page shows the only wiring diagram for the component.power window sub switch door lock switch, which is found in the car Mitsubishi Lancer IX (2000-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram power window sub switch door lock switch (1 of 1)
5 7 (LANCER) (EVOLUTION)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/ORG WIRE
BLU/RED WIRE
DEDICATED FUSE 22
DOOR
ENGINE COMPARTMENT RELAY BOX (ON LEFT SIDE OF ENGINE COMPT)
ETACS ECU JUNCTION BLOCK (BEHIND LEFT END OF DASH)
EVOLUTION
GRY WIRE
HORNS SYSTEM
HOT AT ALL TIMES
HOT IN START OR RUN
JOINT CONNECTOR 1 (BEHIND CENTER OF DASH)
JOINT CONNECTOR 2 (BEHIND INSTRUMENT CLUSTER)
JOINT CONNECTOR 3 (BEHIND RIGHT SIDE OF DASH)
KEY REMINDER
LEFT DOOR LOCK KEY CYLINDER SWITCH (IN LEFT FRONT DOOR)
LEFT FRONT DOOR LOCK ACTUATOR (IN DRIVER'S
LEFT FRONT DOOR SWITCH (AT LEFT FRONT DOOR)
LEFT REAR DOOR LOCK ACTUATOR (IN LEFT
LEFT REAR DOOR SWITCH (AT LEFT REAR DOOR)
LOCK
LT GRN WIRE
MULTI- PURPOSE FUSE 15
MULTI- PURPOSE FUSE 2
NCA WIRE
ORG/ WIRE
PASSENGER'S DOOR
PNK 27 22 WIRE
PNK WIRE
POWER WINDOW MAIN SWITCH (DOOR LOCK SWITCH)
POWER WINDOW SUB SWITCH DOOR LOCK SWITCH
REAR DOOR)
RED WIRE
RED/BLK WIRE
RIGHT FRONT DOOR LOCK ACTUATOR (IN FRONT
RIGHT FRONT DOOR SWITCH (AT RIGHT FRONT DOOR)
RIGHT REAR DOOR LOCK ACTUATOR (IN RIGHT
RIGHT REAR DOOR SWITCH
SWITCH (IN STEERING COLUMN)
UNLOCK
VIO WIRE
WHT WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Power door locks circuit, with keyless entry -> POWER WINDOW SUB SWITCH DOOR LOCK SWITCH
