Mitsubishi Lancer IX (2000-2007) power window sub-switch Wiring diagram
This page shows the only wiring diagram for the component.power window sub-switch, which is found in the car Mitsubishi Lancer IX (2000-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram power window sub-switch (1 of 1)
3 2 PNK WIRE
5 7 (LANCER) (EVOLUTION)
BLK WIRE
BLU WIRE
BLU/RED WIRE
CROSSMEMBER) (LANCER: UNDER RIGHT FRONT KICK PANEL)
DEDICATED FUSE 22
DOOR
DOOR LOCK SWITCH
ENGINE COMPARTMENT RELAY BOX (ON LEFT SIDE OF ENGINE COMPT)
ETACS-ECU
EVOLUTION LANCER
GRY WIRE
HOT AT ALL TIMES
HOT IN START OR RUN
JOINT CONNECTOR 1 (BEHIND CENTER OF DASH)
JOINT CONNECTOR 3 (BEHIND RIGHT SIDE OF DASH)
JUNCTION BLOCK, BEHIND LEFT END OF DASH)
LEFT DOOR LOCK KEY CYLINDER SWITCH (IN LEFT FRONT DOOR)
LEFT FRONT DOOR LOCK ACTUATOR (IN DRIVER'S
LEFT FRONT DOOR SWITCH
LEFT REAR DOOR LOCK ACTUATOR (IN LEFT
LOCK
LT GRN WIRE
MULTI- PURPOSE FUSE 15
MULTI- PURPOSE FUSE 2
NCA WIRE
ORG/ WIRE
PASSENGER'S DOOR
POWER WINDOW MAIN SWITCH
POWER WINDOW SUB-SWITCH
REAR DOOR)
RED WIRE
RED/BLK WIRE
RIGHT FRONT DOOR LOCK ACTUATOR (IN FRONT
RIGHT FRONT DOOR SWITCH
RIGHT REAR DOOR LOCK ACTUATOR (IN RIGHT
UNLOCK
VIO WIRE
WHT WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Power door locks circuit, without keyless entry -> POWER WINDOW SUB-SWITCH
