Mitsubishi Lancer IX (2000-2007) on off down Wiring diagrams
This page contains all the electrical diagrams for the component. on off down, in which he is found in the car Mitsubishi Lancer IX (2000-2007). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram on off down (1 of 2)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
DATA LINK CONNECTOR
DOOR LOCKS SYSTEM
DOWN
ENGINE COMPARTMENT RELAY BOX (ON LEFT SIDE OF ENGINE COMPT)
ETACS-ECU
FUSE 22
FUSIBLE LINK 5
GRN WIRE
GRN/BLK WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
ILLUM
J/C 4
JOINT CONNECTOR
JOINT CONNECTOR 1 (BEHIND CENTER OF DASH)
JUNCTION BLOCK, BEHIND LEFT END OF DASH)
LEFT FRONT DOOR SWITCH
LEFT FRONT POWER WINDOW REGULATOR MOTOR (IN DRIVER'S SIDE DOOR)
LEFT FRONT POWER WINDOW SWITCH
LEFT REAR POWER WINDOW REGULATOR MOTOR (IN LEFT REAR DOOR)
LEFT REAR POWER WINDOW SUB SWITCH
LOCK DOOR LOCK SWITCH
LOCK SWITCH
LOCK UNLOCK
LT GRN WIRE
MULTI- PURPOSE FUSE 2
NCA WIRE
OFF
OFF DOWN
OFF ON
ON OFF DOWN
POWER WINDOW MAIN SWITCH
POWER WINDOW RELAY
RED WIRE
RED/BLK WIRE
RIGHT FRONT DOOR SWITCH
RIGHT FRONT POWER WINDOW REGULATOR MOTOR (IN RIGHT FRONT DOOR)
RIGHT FRONT POWER WINDOW SUB SWITCH
RIGHT REAR POWER WINDOW REGULATOR MOTOR (IN RIGHT REAR DOOR)
RIGHT REAR POWER WINDOW SUB SWITCH
UNLOCK
UP AUTO DOWN
UP LEFT REAR POWER WINDOW SWITCH ON OFF
UP RIGHT FRONT POWER WINDOW SWITCH ON OFF
UP RIGHT REAR POWER WINDOW SWITCH ON OFF
VIO WIRE
WHT WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Power windows circuit, evolution -> ON OFF DOWN
Wiring diagram on off down (2 of 2)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
DATA LINK CONNECTOR (BELOW LEFT SIDE OF DASH)
DOOR LOCKS SYSTEM
DOWN
ENGINE COMPARTMENT RELAY BOX (ON LEFT SIDE OF ENGINE COMPT)
ETACS-ECU
FUSE 22
FUSIBLE LINK 5
GRN WIRE
GRN/BLK WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
ILLUM
JOINT CONNECTOR
JOINT CONNECTOR 1 (BEHIND CENTER OF DASH)
JOINT CONNECTOR 2 (BEHIND INSTRUMENT CLUSTER)
JUNCTION BLOCK, BEHIND LEFT END OF DASH)
LEFT FRONT DOOR SWITCH (AT LEFT FRONT DOOR)
LEFT FRONT POWER WINDOW MOTOR (IN DRIVER'S SIDE DOOR)
LEFT REAR POWER OFF ON ON WINDOW SUB DOWN UP SWITCH
LEFT REAR POWER WINDOW MOTOR (IN LEFT REAR DOOR)
LOCK
LOCK DOOR LOCK SWITCH
LOCK SWITCH
LT GRN WIRE
MULTI- PURPOSE FUSE 2
NCA WIRE
OFF
OFF OFF ON WINDOW SUB DOWN SWITCH
OFF ON
ON OFF DOWN
POWER WINDOW MAIN SWITCH
POWER WINDOW RELAY
RED WIRE
RED/BLK WIRE
RIGHT FRONT DOOR SWITCH (AT RIGHT FRONT DOOR)
RIGHT FRONT POWER
RIGHT FRONT POWER WINDOW MOTOR (IN RIGHT FRONT DOOR)
RIGHT REAR POWER WINDOW MOTOR
RIGHT REAR POWER WINDOW SUB SWITCH
UNLOCK
UP LEFT FRONT POWER WINDOW SWITCH ON OFF
UP LEFT REAR POWER WINDOW SWITCH ON OFF
UP RIGHT FRONT POWER WINDOW SWITCH ON OFF
UP RIGHT REAR POWER WINDOW SWITCH ON OFF
VIO WIRE
WHT WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Power windows circuit, except evolution -> ON OFF DOWN
