Mitsubishi Lancer IX (2000-2007) multi- purpose fuse 12 Wiring diagrams
This page contains all the electrical diagrams for the component. multi- purpose fuse 12, in which he is found in the car Mitsubishi Lancer IX (2000-2007). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram multi- purpose fuse 12 (1 of 2)
ABS ECU (ON RIGHT REAR OF ENGINE COMPARTMENT)
ABS IND.
ABS SOLENOID VALVE
ABS WARNING LIGHT RELAY (ON JUNCTION BLOCK)
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/WHT WIRE
BLU/YEL WIRE
COMBINATION METER
DATA LINK CONNECTOR (BELOW LEFT SIDE OF DASH)
DEDICATED FUSE 10
ENGINE COMPARTMENT RELAY BOX (ON LEFT SIDE OF ENGINE COMPARTMENT)
EXTERIOR LIGHTS SYSTEMS
FUSIBLE LINK 3
GRN WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON
HOT IN ON OR START
HYDRAULIC UNIT
JOINT CONNECTOR 2 (BEHIND INSTRUMENT CLUSTER)
JOINT CONNECTOR 3 (BEHIND RIGHT SIDE OF DASH)
JOINT CONNECTOR 5 (BEHIND INSTRUMENT CLUSTER)
JOINT CONNECTOR 6 (BEHIND LOWER CENTER OF DASH)
JUNCTION BLOCK, BEHIND LEFT END OF DASH)
LEFT FRONT WHEEL SPEED SENSOR (ON LEFT FRONT WHEEL HUB ASSEMBLY)
LEFT REAR WHEEL SPEED SENSOR (AT LEFT REAR WHEEL)
LT GRN WIRE
MULTI- PURPOSE FUSE 12
MULTI- PURPOSE FUSE 2
NCA WIRE
ORG/ WIRE
PNK WIRE
RED WIRE
RED YEL/ WIRE
RED/YEL WIRE
RIGHT FRONT WHEEL SPEED SENSOR (ON RIGHT FRONT WHEEL HUB ASSEMBLY)
RIGHT REAR WHEEL SPEED SENSOR (AT RIGHT REAR WHEEL)
STOPLIGHT SWITCH (ABOVE BRAKE PEDAL, ON BRACKET)
WHT WIRE
Go to component -> Anti-lock brakes circuit, except evolution -> MULTI- PURPOSE FUSE 12
Wiring diagram multi- purpose fuse 12 (2 of 2)
