Mitsubishi Lancer IX (2000-2007) malfunction ind light Wiring diagrams
This page contains all the electrical diagrams for the component. malfunction ind light, in which he is found in the car Mitsubishi Lancer IX (2000-2007). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram malfunction ind light (1 of 2)
ABS IND.
ANTI-LOCK BRAKES SYSTEM
ANTI-THEFT SYSTEM
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRAKE FLUID LEVEL INDICATOR SWITCH (ON BRAKE FLUID MASTER CYLINDER RESERVOIR)
BRAKE IND
CHARGE IND
COMBINATION METER
CONTROL CIRCUIT
DOOR IND
ENGINE CONTROLS SYSTEM
ENGINE COOLANT TEMPERATURE GAUGE UNIT (LEFT REAR OF ENGINE)
ETACS-ECU
FOG IND
FUEL GAUGE
FUEL IND
FUSE 2
GRN WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
HEADLIGHTS SYSTEM
HIGH BEAM IND
HOT IN ON OR START
ILLUMINATION
JOINT CONNECTOR 4
JUNCTION BLOCK, BEHIND LEFT END OF DASH)
LEFT TURN IND
LT GRN WIRE
MALFUNCTION IND LIGHT
NCA WIRE
ODOMETER/TRIP
OIL IND
OIL PRESSURE SWITCH (AT REAR OF ENGINE)
ORG/ WIRE
PARKING BRAKE SWITCH (AT BASE OF PARKING BRAKE LEVER)
PNK WIRE
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RIGHT TURN IND
SEAT BELT IND
SECURITY IND
SPEEDOMETER
SRS IND
STARTING/CHARGING SYSTEM HEADLIGHTS SYSTEM
TACHOMETER
TEMPERATURE GAUGE
VIO WIRE
WARNING SYSTEM SUPPLEMENTAL RESTRAINTS SYSTEM
WATER SPRAY IND
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Instrument cluster circuit, evolution (1 of 2) -> MALFUNCTION IND LIGHT
Wiring diagram malfunction ind light (2 of 2)
A/T
ABS IND.
ANTI-LOCK BRAKES SYSTEM
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRAKE FLUID LEVEL INDICATOR SWITCH (ON BRAKE FLUID MASTER CYLINDER RESERVOIR)
BRAKE IND
BRN WIRE
CHARGE IND
COMBINATION METER
CONTROL CIRCUIT
CRUISE CONTROL SYSTEM
CRUISE IND
DOOR IND
ENGINE COOLANT TEMPERATURE GAUGE UNIT (ON REAR OF ENGINE)
ENGINE OIL PRESSURE SWITCH (ON RIGHT FRONT OF ENGINE)
ETACS-ECU
FOG IND
FUEL GAUGE
FUEL IND
FUSE 2
FUSE 3
GRN WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
HEADLIGHTS SYSTEM
HIGH BEAM IND
HOT IN ON OR START
ILLUMINATION
JUNCTION BLOCK, BEHIND LEFT END OF DASH)
LEFT TURN IND
LT GRN WIRE
M/T JOINT CONNECTOR 5 (BEHIND INSTRUMENT CLUSTER)
MALFUNCTION IND LIGHT
NCA WIRE
ODOMETER/TRIP
OIL IND
ORG/ WIRE
PARKING BRAKE SWITCH (AT BASE OF PARKING BRAKE LEVER)
PNK WIRE
RED WIRE
RED/BLK WIRE
RIGHT TURN IND
SEAT BELT IND
SPEEDOMETER
SRS IND
STARTING/CHARGING SYSTEM HEADLIGHTS SYSTEM
TACHOMETER
TEMPERATURE GAUGE
WARNING SYSTEM SUPPLEMENTAL RESTRAINTS SYSTEM
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> Instrument cluster circuit, except evolution (1 of 2) -> MALFUNCTION IND LIGHT
