Mitsubishi Lancer IX (2000-2007) left rear door lock actuator (in left Wiring diagrams
This page contains all the electrical diagrams for the component. left rear door lock actuator (in left, in which he is found in the car Mitsubishi Lancer IX (2000-2007). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left rear door lock actuator (in left (1 of 2)
5 7 (LANCER) (EVOLUTION)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/ORG WIRE
BLU/RED WIRE
DEDICATED FUSE 22
DOOR
ENGINE COMPARTMENT RELAY BOX (ON LEFT SIDE OF ENGINE COMPT)
ETACS ECU JUNCTION BLOCK (BEHIND LEFT END OF DASH)
EVOLUTION
GRY WIRE
HORNS SYSTEM
HOT AT ALL TIMES
HOT IN START OR RUN
JOINT CONNECTOR 1 (BEHIND CENTER OF DASH)
JOINT CONNECTOR 2 (BEHIND INSTRUMENT CLUSTER)
JOINT CONNECTOR 3 (BEHIND RIGHT SIDE OF DASH)
KEY REMINDER
LEFT DOOR LOCK KEY CYLINDER SWITCH (IN LEFT FRONT DOOR)
LEFT FRONT DOOR LOCK ACTUATOR (IN DRIVER'S
LEFT FRONT DOOR SWITCH (AT LEFT FRONT DOOR)
LEFT REAR DOOR LOCK ACTUATOR (IN LEFT
LEFT REAR DOOR SWITCH (AT LEFT REAR DOOR)
LOCK
LT GRN WIRE
MULTI- PURPOSE FUSE 15
MULTI- PURPOSE FUSE 2
NCA WIRE
ORG/ WIRE
PASSENGER'S DOOR
PNK 27 22 WIRE
PNK WIRE
POWER WINDOW MAIN SWITCH (DOOR LOCK SWITCH)
POWER WINDOW SUB SWITCH DOOR LOCK SWITCH
REAR DOOR)
RED WIRE
RED/BLK WIRE
RIGHT FRONT DOOR LOCK ACTUATOR (IN FRONT
RIGHT FRONT DOOR SWITCH (AT RIGHT FRONT DOOR)
RIGHT REAR DOOR LOCK ACTUATOR (IN RIGHT
RIGHT REAR DOOR SWITCH
SWITCH (IN STEERING COLUMN)
UNLOCK
VIO WIRE
WHT WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Power door locks circuit, with keyless entry -> LEFT REAR DOOR LOCK ACTUATOR (IN LEFT
Wiring diagram left rear door lock actuator (in left (2 of 2)
3 2 PNK WIRE
5 7 (LANCER) (EVOLUTION)
BLK WIRE
BLU WIRE
BLU/RED WIRE
CROSSMEMBER) (LANCER: UNDER RIGHT FRONT KICK PANEL)
DEDICATED FUSE 22
DOOR
DOOR LOCK SWITCH
ENGINE COMPARTMENT RELAY BOX (ON LEFT SIDE OF ENGINE COMPT)
ETACS-ECU
EVOLUTION LANCER
GRY WIRE
HOT AT ALL TIMES
HOT IN START OR RUN
JOINT CONNECTOR 1 (BEHIND CENTER OF DASH)
JOINT CONNECTOR 3 (BEHIND RIGHT SIDE OF DASH)
JUNCTION BLOCK, BEHIND LEFT END OF DASH)
LEFT DOOR LOCK KEY CYLINDER SWITCH (IN LEFT FRONT DOOR)
LEFT FRONT DOOR LOCK ACTUATOR (IN DRIVER'S
LEFT FRONT DOOR SWITCH
LEFT REAR DOOR LOCK ACTUATOR (IN LEFT
LOCK
LT GRN WIRE
MULTI- PURPOSE FUSE 15
MULTI- PURPOSE FUSE 2
NCA WIRE
ORG/ WIRE
PASSENGER'S DOOR
POWER WINDOW MAIN SWITCH
POWER WINDOW SUB-SWITCH
REAR DOOR)
RED WIRE
RED/BLK WIRE
RIGHT FRONT DOOR LOCK ACTUATOR (IN FRONT
RIGHT FRONT DOOR SWITCH
RIGHT REAR DOOR LOCK ACTUATOR (IN RIGHT
UNLOCK
VIO WIRE
WHT WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Power door locks circuit, without keyless entry -> LEFT REAR DOOR LOCK ACTUATOR (IN LEFT
