Mitsubishi Lancer IX (2000-2007) left front door speaker right front door speaker Wiring diagram
This page shows the only wiring diagram for the component.left front door speaker right front door speaker, which is found in the car Mitsubishi Lancer IX (2000-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front door speaker right front door speaker (1 of 1)
ANTENNA AMPLIFIER
BLK/YEL WIRE
BLU/YEL WIRE
CD AUTO CHANGER
DIN CABLE
ENGINE COMPARTMENT RELAY BOX (ON LEFT SIDE OF ENGINE COMPARTMENT)
FUSE 20
FUSE 22
FUSE 23
GRN WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
HOT IN ON OR ACC
HOT W/ TAILLIGHT RELAY ENERGIZED
JOINT CONNECTOR 1 (BEHIND CENTER OF DASH)
LEFT FRONT DOOR SPEAKER RIGHT FRONT DOOR SPEAKER
LEFT REAR DOOR SPEAKER
LEFT TWEETER (W/ RADIO, CD PLAYER)
LT GRN WIRE
NCA WIRE
PNK WIRE
RADIO, CD PLAYER
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
RIGHT REAR DOOR SPEAKER
RIGHT TWEETER (W/ RADIO, CD PLAYER)
ROOF ANTENNA
VIO WIRE
WHT/BLU WIRE
YEL WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> 6-speaker system circuit, evolution without amplifier -> LEFT FRONT DOOR SPEAKER RIGHT FRONT DOOR SPEAKER
