Mitsubishi Lancer IX (2000-2007) horns, door locks systems Wiring diagram
This page shows the only wiring diagram for the component.horns, door locks systems, which is found in the car Mitsubishi Lancer IX (2000-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram horns, door locks systems (1 of 1)
AIR CONDITIONING, COOLING FANS SYSTEMS
ANTI-LOCK BRAKES SYSTEM
BATTERY
BLK WIRE
BLK/PNK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRN WIRE
CRUISE CONTROL, ENGINE CONTROLS, TRANSMISSIONS SYSTEMS
DOOR LOCKS, EXTERIOR LIGHTS SYSTEMS TRANSMISSIONS SYSTEM
ENGINE COMPARTMENT RELAY BOX (ON LEFT SIDE OF ENGINE COMPARTMENT)
ENGINE CONTROLS SYSTEM
EXTERIOR LIGHTS, INSTRUMENT CLUSTER, CRUISE CONTROL, POWER TOPS
FRONT ECU
FUSE 12
FUSE 13 FUSE 14
FUSE 15
FUSE 16
FUSE 17
FUSE 18
FUSE 19
FUSE 20
FUSE 21
FUSE 22
FUSE 6
FUSE 7
FUSE 8
FUSE 9 FUSE 10
FUSIBLE LINK 1
FUSIBLE LINK 2
FUSIBLE LINK 3
FUSIBLE LINK 4
FUSIBLE LINK 5
GRN WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
HEADLIGHT RELAY (HIGH)
HEADLIGHT RELAY (LOW)
HEADLIGHTS SYSTEM
HEADLIGHTS SYSTEM HEADLIGHTS SYSTEM
HORNS, DOOR LOCKS SYSTEMS
OFF
ORG/ WIRE
PNK WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
STARTING/ CHARGING SYSTEM
SYSTEMS
TAILLIGHT RELAY
TO FUSE 15 (DIAGRAM 2 OF 2)
TO IGNITION SWITCH (DIAGRAM 2 OF 2)
TO JUNCTION BLOCK (DIAGRAM 2 OF 2)
WHT WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Power distribution circuit, except evolution (1 of 2) -> HORNS, DOOR LOCKS SYSTEMS
