Mitsubishi Lancer IX (2000-2007) except canada headlight relay low Wiring diagram
This page shows the only wiring diagram for the component.except canada headlight relay low, which is found in the car Mitsubishi Lancer IX (2000-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram except canada headlight relay low (1 of 1)
BEAM IND
BLK WIRE
BLU WIRE
BRN WIRE
CANADA
COLUMN ECU
COLUMN SWITCH (ON TOP OF STEERING COLUMN)
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DEDICATED FUSE 16
DEDICATED FUSE 17 DEDICATED FUSE 18
DEDICATED FUSE 19
DEDICATED FUSE 22
DEDICATED FUSE 6
DIMMER, PASSING SWITCH
ENGINE COMPARTMENT RELAY BOX (ON LEFT SIDE OF ENGINE COMPT)
ETACS-ECU
EXCEPT CANADA HEADLIGHT RELAY LOW
FOG IND
FOG LIGHT RELAY (ON ENGINE COMPARTMENT RELAY BOX)
FOG LIGHT SWITCH
FRONT ECU
FRONT ECU (IN ENGINE COMPT RELAY BOX)
GRN WIRE
GRY WIRE
HEAD
HEADLIGHT RELAY (HIGH)
HOT AT ALL TIMES
HOT IN ON
HOT IN ON OR START
ILLUM
J/C 3 (BEHIND RIGHT SIDE OF DASH)
JOINT CONN- ECTOR 2 (BEHIND INSTRU- MENT CLUSTER)
JOINT CONNECTOR 1 (BEHIND CENTER OF DASH)
JOINT CONNECTOR 3 (BEHIND RIGHT SIDE OF DASH)
JOINT CONNECTOR 5 (BEHIND INSTRUMENT CLUSTER)
JUNCTION BLOCK, BEHIND LEFT END OF DASH)
LEFT FRONT DOOR SWITCH (AT LEFT FRONT DOOR)
LEFT HEADLIGHT
LIGHTING SWITCH
LOW FIELD EFFECT TRANSISTOR FOR HEADLIGHT
LT GRN WIRE
MULTI- PURPOSE FUSE 2
MULTI- PURPOSE FUSE 5
NCA WIRE
OFF
ON OFF ON
PASS LO
PNK WIRE
PULSE WIDTH MODULATION ON
RED WIRE
RED/BLK WIRE
RIGHT HEADLIGHT
TAIL OFF
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> Headlights circuit, except evolution -> EXCEPT CANADA HEADLIGHT RELAY LOW
