Mitsubishi Lancer IX (2000-2007) defogger system Wiring diagrams
This page contains all the electrical diagrams for the component. defogger system, in which he is found in the car Mitsubishi Lancer IX (2000-2007). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
defogger system wiring diagram (1 of 5)
4 5 6 PNK WIRE
A/C SWITCH, OUTSIDE/INSIDE AIR SELECTION DAMPER CONTROL, ILLUMINATION
A/C- ECU
AIR THERMO SENSOR (BEHIND RIGHT CENTER OF OF DASH, ON HVAC UNIT)
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLOWER MOTOR (BEHIND RIGHT END OF DASH)
BLOWER RELAY
BLOWER SWITCH
BLU WIRE
BLU/BLK WIRE
BRN WIRE
COOLING FAN MOTOR
DEFOGGER SYSTEM
FAN CONTROL MODULE (ON FAN SHROUD, AT LEFT FRONT OF ENGINE COMPT)
FUSE 19
FUSE 5
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT IN ON
INLET SIDE
JOINT CONNECTOR 2 (BEHIND INSTRUMENT CLUSTER)
JOINT CONNECTOR 3 (BEHIND RIGHT SIDE OF DASH)
JUNCTION BLOCK, BEHIND LEFT END OF DASH)
LT GRN WIRE
NCA WIRE
OFF LO ML MH
OUTLET SIDE
PNK WIRE
RED WIRE
RED/YEL WIRE
RESISTOR (BEHIND RIGHT SIDE OF DASH, ON HVAC UNIT)
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Manual a/c circuit, evolution (1 of 2) -> DEFOGGER SYSTEM
defogger system wiring diagram (2 of 5)
A/C-ECU (BEHIND CENTER OF DASH, BELOW RADIO)
AIR THERMO SENSOR (BEHIND RIGHT CENTER OF OF DASH, ON HVAC UNIT)
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLOWER MOTOR (BEHIND RIGHT END OF DASH)
BLOWER RELAY
BLOWER SWITCH
BLU WIRE
BLU/BLK WIRE
BRN WIRE
CONDENSER FAN MOTOR (MOUNTED ON REAR OF RADIATOR)
DEFOGGER SYSTEM
FAN CONTROL MODULE (ON FAN SHROUD, AT LEFT FRONT OF ENGINE COMPARTMENT)
FUSE 19
FUSE 5
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HEATER CONTROL PANEL, ILLUMINATION
HOT AT ALL TIMES
HOT IN ON
INLET SIDE
JOINT CONNECTOR 2 (BEHIND INSTRUMENT CLUSTER)
JOINT CONNECTOR 3 (BEHIND RIGHT SIDE OF DASH)
JUNCTION BLOCK, BEHIND LEFT END OF DASH)
LT GRN WIRE
NCA WIRE
OFF LO 4 5 ML MH
OUTLET SIDE
RADIATOR FAN MOTOR
RED WIRE
RED/YEL WIRE
RESISTOR (BEHIND RIGHT SIDE OF DASH, ON HVAC UNIT)
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Manual a/c circuit, except evolution (1 of 2) -> DEFOGGER SYSTEM
defogger system wiring diagram (3 of 5)
AIR CONDITIONING SYSTEM
ANTI-LOCK BRAKES, POWER TOPS SYSTEMS
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
CIGARETTE LIGHTER
DEFOGGER SYSTEM
ENGINE COMPARTMENT RELAY BOX (ON LEFT SIDE OF ENGINE COMPARTMENT)
ENGINE CONTROLS SYSTEM
EXTERIOR LIGHTS, WIPER/WASHER, SUPPLEMENTAL RESTRAINTS SYSTEMS
FROM FUSIBLE LINK 1 (DIAGRAM 1 OF 2)
FROM FUSIBLE LINK 4 (DIAGRAM 1 OF 2)
FROM FUSIBLE LINK 5 (DIAGRAM 1 OF 2)
FUSE 12
FUSE 14
FUSE 15
FUSE 19 FUSE 20 FUSE 21
FUSE 2 FUSE 1
FUSE 23
FUSE 3 FUSE 8
FUSE 5
FUSE 7 FUSE 11
FUSE 9
GRN WIRE
IGNITION SWITCH
INSTRUMENT CLUSTER, INTERIOR LIGHTS, SOUND SYSTEMS
JUNCTION BLOCK, BEHIND LEFT END OF DASH)
LOCK
LOCK OFF
ON OFF
POWER TOPS SYSTEM
POWER WINDOWS SYSTEM
RED WIRE
STARTING/CHARGING SYSTEM
WHT WIRE
WIPER/WASHER SYSTEM MIRRORS SYSTEM
WIPER/WASHER, INTERIOR LIGHTS SYSTEMS
Go to component -> Power distribution circuit, evolution (2 of 2) -> DEFOGGER SYSTEM
defogger system wiring diagram (4 of 5)
AIR CONDITIONING SYSTEM
AIR CONDITIONING, WIPER/WASHER, HEADLIGHTS, EXTERIOR LIGHTS SYSTEMS
ANTI-LOCK BRAKES, POWER TOPS SYSTEM
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BRN WIRE
CIGARETTE LIGHTER
CRUISE CONTROL SYSTEM
DEFOGGER SYSTEM
ENGINE COMPARTMENT RELAY BOX (ON LEFT SIDE OF ENGINE COMPARTMENT)
ENGINE CONTROLS SYSTEM
FROM FUSIBLE LINK 1 (DIAGRAM 1 OF 2)
FROM FUSIBLE LINK 4 (DIAGRAM 1 OF 2)
FROM FUSIBLE LINK 5 (DIAGRAM 1 OF 2)
FUSE 1
FUSE 12
FUSE 14
FUSE 15
FUSE 19
FUSE 2
FUSE 20
FUSE 21
FUSE 23
FUSE 3
FUSE 4 (2.0L)
FUSE 5
FUSE 7 FUSE 11
FUSE 8
FUSE 9
GRN WIRE
IGNITION SWITCH
INSTRUMENT CLUSTER, INTERIOR LIGHTS, SOUND SYSTEMS
JUNCTION BLOCK, BEHIND LEFT END OF DASH)
LOCK
LOCK OFF
MIRRORS SYSTEM
ON OFF
POWER TOPS SYSTEM
POWER WINDOWS SYSTEM
RED WIRE
STARTING/CHARGING, ENGINE CONTROLS, TRANSMISSIONS, CRUISE CONTROL SYSTEMS
TRANSMISSIONS, ENGINE CONTROLS SYSTEMS
WHT WIRE
WIPER/WASHER SYSTEM
WIPER/WASHER, INTERIOR LIGHTS SYSTEMS
YEL WIRE
Go to component -> Power distribution circuit, except evolution (2 of 2) -> DEFOGGER SYSTEM
defogger system wiring diagram (5 of 5)
BLK WIRE
BLU WIRE
BRN WIRE
DEFOGGER SYSTEM
DOWN
GRN WIRE
GRY WIRE
HOT IN ACC OR ON
JOINT CONNECTOR
JUNCTION BLOCK, BEHIND LEFT END OF DASH)
LEFT
LEFT REMOTE CONTROLLED MIRROR HTR
LEFT RIGHT OFF
MULTI- PURPOSE FUSE 11
NCA WIRE
RED WIRE
REMOTE CONTROLLED MIRROR SWITCH
RIGHT
RIGHT REMOTE CONTROLLED MIRROR HTR
W/ MIRROR HEATER W/O MIRROR HEATER
WHT WIRE
WHT/BLU WIRE
YEL/GRN WIRE
Go to component -> Power mirrors circuit, except evolution -> DEFOGGER SYSTEM
