Mitsubishi Lancer IX (2000-2007) charge indicator Wiring diagram
This page shows the only wiring diagram for the component.charge indicator, which is found in the car Mitsubishi Lancer IX (2000-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram charge indicator (1 of 1)
41 54 86 86 2.0L M/T 2.0L A/T 2.4L M/T 2.4L A/T 33 8 45 45
BATTERY
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/WHT WIRE
CHARGE INDICATOR
COMB- INATION METER
DEDICATED FUSE 12
ENGINE COMP- ARTMENT RELAY BOX (ON LEFT SIDE OF ENGINE COMPT)
ENGINE CONTROL MODULE (M/T)
FUSIBLE LINK 26
FUSIBLE LINK 4
GENERATOR 4 2 FR
IGNITION SWITCH
JOINT CONNECTOR 5 (BEHIND INSTRUMENT CLUSTER)
JUNCTION BLOCK (BEHIND LEFT END OF DASH) MULTI- PURPOSE FUSE 2
LOCK
NCA WIRE
ON OFF
ORG/ WIRE
POWERTRAIN CONTROL MODULE (A/T) (BEHIND GLOVE BOX)
RED WIRE
STARTING CIRCUIT
WHT WIRE
WHT/RED WIRE
YEL WIRE
YEL/RED WIRE
