Mitsubishi Lancer IX (2000-2007) a/c switch, outside/inside air selection damper control, illumination Wiring diagram
This page shows the only wiring diagram for the component.a/c switch, outside/inside air selection damper control, illumination, which is found in the car Mitsubishi Lancer IX (2000-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram a/c switch, outside/inside air selection damper control, illumination (1 of 1)
4 5 6 PNK WIRE
A/C SWITCH, OUTSIDE/INSIDE AIR SELECTION DAMPER CONTROL, ILLUMINATION
A/C- ECU
AIR THERMO SENSOR (BEHIND RIGHT CENTER OF OF DASH, ON HVAC UNIT)
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLOWER MOTOR (BEHIND RIGHT END OF DASH)
BLOWER RELAY
BLOWER SWITCH
BLU WIRE
BLU/BLK WIRE
BRN WIRE
COOLING FAN MOTOR
DEFOGGER SYSTEM
FAN CONTROL MODULE (ON FAN SHROUD, AT LEFT FRONT OF ENGINE COMPT)
FUSE 19
FUSE 5
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT IN ON
INLET SIDE
JOINT CONNECTOR 2 (BEHIND INSTRUMENT CLUSTER)
JOINT CONNECTOR 3 (BEHIND RIGHT SIDE OF DASH)
JUNCTION BLOCK, BEHIND LEFT END OF DASH)
LT GRN WIRE
NCA WIRE
OFF LO ML MH
OUTLET SIDE
PNK WIRE
RED WIRE
RED/YEL WIRE
RESISTOR (BEHIND RIGHT SIDE OF DASH, ON HVAC UNIT)
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Manual a/c circuit, evolution (1 of 2) -> A/C SWITCH, OUTSIDE/INSIDE AIR SELECTION DAMPER CONTROL, ILLUMINATION
