Mitsubishi Lancer IX (2000-2007) 21 22 air bag drive circuit Wiring diagram

1 2 PNK WIRE 21 22 AIR BAG DRIVE CIRCUIT 23 24 AIR BAG DRIVE CIRCUIT 27 28 AIR BAG DRIVE CIRCUIT 29 30 AIR BAG DRIVE CIRCUIT 32 33 34 35 36 37 38 39 40 41 42 C-13 BLK WIRE BLK/BLU WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE C-01 C-02 C-13 C-214 COMBINATION METER CONNECTOR LOCK SWITCH (CONNECTOR COUPLED: ON) (CONNECTOR UNCOUPLED: OFF) FUSE 2 FUSE 3 GRN WIRE GRN/YEL WIRE GROUND HOT IN ON OR START INTERFACE J/C 5 (BEHIND COMBINATION METER) JUNCTION BLOCK, BEHIND LEFT END OF DASH) LEFT SEAT BELT PRETENSIONER (AT BASE OF LEFT "B" PILLAR, BEHIND TRIM) LEFT SIDE AIR BAG MODULE SQUIB (W/SIDE AIR BAGS) (AT DRIVER'S SEAT) NCA WIRE OFF OFF ON ON OFF ORG/ WIRE PNK WIRE RED WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE RIGHT SEAT BELT PRETENSIONER (AT BASE OF RIGHT "B" PILLAR, BEHIND TRIM) SOLID STATE SRS ECU (BEHIND LOWER CENTER OF DASH) SRS INDICATOR VIO WIRE WHT WIRE WHT/BLU WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE YEL/RED WIRE
