Power distribution circuit for Mitsubishi Galant VIII facelift (1998-2006)

AIR CONDITIONING SYSTEM AIR CONDITIONING, COOLING FANS SYSTEMS ANTI-LOCK BRAKES SYSTEM BATTERY BLK/BLU WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/YEL WIRE BRN/WHT WIRE CRUISE CONTROL, COMPUTER DATA LINES, TRANSMISSIONS, ENGINE CONTROLS SYSTEMS DOOR LOCKS, EXTERIOR LIGHTS SYSTEMS STARTING/ CHARGING SYSTEM ENGINE COMPARTMENT RELAY BOX (AT LEFT SIDE OF ENGINE COMPARTMENT) ENGINE CONTROLS SYSTEM FRONT ECU FUSE 10 FUSE 11 FUSE 14 FUSE 13 FUSE 15 FUSE 7 FUSE 16 FUSE 17 FUSE 18 FUSE 19 FUSE 20 FUSE 21 FUSE 22 FUSE 24 FUSE 3 FUSE 4 FUSE 6 FUSE 9 FUSE 8 FUSIBLE LINK 1 FUSIBLE LINK 2 FUSIBLE LINK 27 FUSIBLE LINK 3 FUSIBLE LINK 4 FUSIBLE LINK 5 GRN/BLK WIRE GRN/ORG WIRE GRN/WHT WIRE HEADLIGHT RELAY (HIGH) HEADLIGHT RELAY LOW PULSE WIDTH MODULATOR HEADLIGHTS SYSTEM HEADLIGHTS SYSTEM HEADLIGHTS SYSTEM HORNS, DOOR LOCKS, ANTI-THEFT SYSTEMS JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) POWER WINDOW RELAY LT GRN/RED WIRE OFF ORG/BLU WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/WHT WIRE SEATS SYSTEM SOUND SYSTEMS POWER TOPS SYSTEM STARTING/ CHARGING SYSTEM TAILLIGHT RELAY TO FUSE 10 (DIAGRAM 2 OF 2) TO IGNITION SWITCH (DIAGRAM 2 OF 2) TRANSMISSIONS SYSTEM SEATS SYSTEM WHT WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE YEL/RED WIRE

ACCESSORY SOCKET 1 (+) ACCESSORY SOCKET 2 ACCESSORY SOCKET RELAY AIR CONDITIONING SYSTEM AIR CONDITIONING, NAVIGATION SYSTEMS BLK WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE DEFOGGER RELAY ENGINE COMPARTMENT RELAY BOX (AT LEFT SIDE OF ENGINE COMPARTMENT) ENGINE CONTROLS SYSTEM FROM FUSE 20 (DIAGRAM 2 OF 2) FROM FUSIBLE LINK 1 (DIAGRAM 1 OF 2) FROM FUSIBLE LINK 4 (DIAGRAM 1 OF 2) FUSE 10 FUSE 14 FUSE 17 FUSE 20 FUSE 13 FUSE 11 FUSE 22 FUSE 24 FUSE 23 FUSE 25 FUSE 5 FUSE 6 FUSE 9 IGNITION SWITCH INTERIOR LIGHTS, DOOR LOCKS, WIPER/WASHER SYSTEMS JOINT CONNECTOR 2 LOCK LOCK OFF LOCK OFF ON MIRRORS SYSTEM ON OFF POWER TOPS SYSTEM RED WIRE STARTING/ CHARGING, CRUISE CONTROL SYSTEMS TO DEFOGGER RELAY RELAY (DIAGRAM 2 OF 2) WHT WIRE WIPER/WASHER SYSTEM YEL WIRE
