Mitsubishi Galant VIII facelift (1998-2006) cruise control, computer data lines, transmissions, engine controls systems Wiring diagram
This page shows the only wiring diagram for the component.cruise control, computer data lines, transmissions, engine controls systems, which is found in the car Mitsubishi Galant VIII facelift (1998-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cruise control, computer data lines, transmissions, engine controls systems (1 of 1)
AIR CONDITIONING SYSTEM
AIR CONDITIONING, COOLING FANS SYSTEMS
ANTI-LOCK BRAKES SYSTEM
BATTERY
BLK/BLU WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/YEL WIRE
BRN/WHT WIRE
CRUISE CONTROL, COMPUTER DATA LINES, TRANSMISSIONS, ENGINE CONTROLS SYSTEMS
DOOR LOCKS, EXTERIOR LIGHTS SYSTEMS STARTING/ CHARGING SYSTEM
ENGINE COMPARTMENT RELAY BOX (AT LEFT SIDE OF ENGINE COMPARTMENT)
ENGINE CONTROLS SYSTEM
FRONT ECU
FUSE 10
FUSE 11
FUSE 14 FUSE 13
FUSE 15 FUSE 7
FUSE 16
FUSE 17
FUSE 18
FUSE 19
FUSE 20
FUSE 21
FUSE 22
FUSE 24
FUSE 3 FUSE 4
FUSE 6
FUSE 9 FUSE 8
FUSIBLE LINK 1
FUSIBLE LINK 2
FUSIBLE LINK 27
FUSIBLE LINK 3
FUSIBLE LINK 4
FUSIBLE LINK 5
GRN/BLK WIRE
GRN/ORG WIRE
GRN/WHT WIRE
HEADLIGHT RELAY (HIGH)
HEADLIGHT RELAY LOW PULSE WIDTH MODULATOR
HEADLIGHTS SYSTEM
HEADLIGHTS SYSTEM HEADLIGHTS SYSTEM
HORNS, DOOR LOCKS, ANTI-THEFT SYSTEMS
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) POWER WINDOW RELAY
LT GRN/RED WIRE
OFF
ORG/BLU WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
SEATS SYSTEM
SOUND SYSTEMS POWER TOPS SYSTEM
STARTING/ CHARGING
SYSTEM
TAILLIGHT RELAY
TO FUSE 10 (DIAGRAM 2 OF 2)
TO IGNITION SWITCH (DIAGRAM 2 OF 2)
TRANSMISSIONS SYSTEM SEATS SYSTEM
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Power distribution circuit (1 of 2) -> CRUISE CONTROL, COMPUTER DATA LINES, TRANSMISSIONS, ENGINE CONTROLS SYSTEMS
