Exterior lamps circuit for Mitsubishi Galant VIII (1996-1999)

BLK WIRE COLUMN SWITCH ENGINE COMPARTMENT RELAY BOX (ON RIGHT INNER FENDER PANEL) ENGINE COMPARTMENT RELAY BOX (ON RIGHT INNER FENDER PANEL) DEDICATED FUSE 8 FUSIBLE LINK 6 GRN WIRE GRN/WHT WIRE HEAD HIGH MOUNTED STOP LIGHT HOT AT ALL TIMES JUNCTION BLOCK 1 (AT LEFT SIDE KICK PANEL) JUNCTION BLOCK 2 (AT LEFT SIDE KICK PANEL) LEFT POSITION AND SIDE MARKER LIGHT LEFT REAR COMBINATION LIGHT LEFT REAR LID LIGHT LEFT REAR SIDE MARKER LIGHT LICENSE PLATE LIGHT MULTI- PURPOSE FUSE 5 NCA WIRE OFF ORG/ GRN WIRE ORG/ WIRE RED WIRE RIGHT POSITION AND SIDE MARKER LIGHT RIGHT REAR COMBINATION LIGHT RIGHT REAR LID LIGHT RIGHT REAR SIDE MARKER LIGHT STOP LIGHT SWITCH (ON BRAKE PEDAL BRACKET) STOP STOP TAIL TAIL TAILLIGHT RELAY (IN ENGINE COMPT RELAY BOX) TO JUNCTION BLOCK 2 (DIAGRAM 2 OF 2) W/ CRUISE W/O CRUISE WHT WIRE

BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE COLUMN SWITCH (TURN SIGNAL SWITCH) COMBINATION METER DEDICATED FUSE 4 ENGINE COMPARTMENT RELAY BOX (ON RIGHT INNER FENDER PANEL) FROM JUNCTION BLOCK 1 (DIAGRAM 1 OF 2) GRN WIRE GRN/BLU WIRE GRN/RED (OR GRN/BLU) WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HAZARD WARNING SWITCH HOT AT ALL TIMES HOT IN ON OR START ILLUMINATION JUNCTION BLOCK 1 (AT LEFT SIDE KICK PANEL) JUNCTION BLOCK 2 (AT LEFT SIDE KICK PANEL) LEFT LEFT FRONT TURN LIGHT LEFT IND LEFT REAR COMBINATION LIGHT LEFT TURN MULTI- PURPOSE FUSE 4 OFF OFF ON RED WIRE RED/BLU WIRE RHEOSTAT RIGHT RIGHT FRONT TURN LIGHT RIGHT IND RIGHT REAR COMBINATION LIGHT RIGHT TURN TURN SIGNAL AND HAZARD FLASHER UNIT (LEFT KICK PANEL, ON JUNCTION BLOCK 1)
