Mitsubishi Galant VIII (1996-1999) on off off right front power window motor Wiring diagram
This page shows the only wiring diagram for the component.on off off right front power window motor, which is found in the car Mitsubishi Galant VIII (1996-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram on off off right front power window motor (1 of 1)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BRN/WHT WIRE
DEDICATED FUSE 12
DOWN
DOWN UP
ENGINE COMPARTMENT RELAY BOX (ON RIGHT INNER FENDER PANEL)
FUSIBLE LINK 7
GRN WIRE
GRN/BLK WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON
JUNCTION BLOCK 1 (AT LEFT SIDE KICK PANEL)
JUNCTION BLOCK 2 (AT LEFT SIDE KICK PANEL)
JUNCTION JUNCTION BLOCK 1 BLOCK 1 (AT LEFT SIDE KICK PANEL)
JUNCTION JUNCTION BLOCK 2 (AT LEFT SIDE KICK PANEL)
LEFT FRONT
LEFT FRONT DOOR SWITCH
LEFT FRONT POWER WINDOW MOTOR
LEFT FRONT POWER WINDOW SWITCH
LEFT REAR
LEFT REAR POWER WINDOW MOTOR
LEFT REAR POWER WINDOW SWITCH
LOCK
LOCK SWITCH
MULTI- PURPOSE FUSE 13
NCA WIRE
OFF
ON OFF
ON OFF OFF RIGHT FRONT POWER WINDOW MOTOR
ON ON OFF OFF
POWER WINDOW SUB- SWITCH DOWN
POWER WINDOW SUB-SWITCH
RED/BLK WIRE
RED/BLU WIRE
RIGHT FRONT
RIGHT FRONT POWER WINDOW SWITCH
RIGHT REAR AUTO DOWN SWITCH UP
RIGHT REAR POWER WINDOW MOTOR
RIGHT REAR POWER WINDOW SWITCH
SOLID STATE
UNLOCK
UP DOWN
W/ KEYLESS ENTRY
W/O KEYLESS ENTRY
YEL/BLK WIRE
YEL/WHT WIRE
