Mitsubishi Galant VIII (1996-1999) circuit breaker frt Wiring diagram
This page shows the only wiring diagram for the component.circuit breaker frt, which is found in the car Mitsubishi Galant VIII (1996-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram circuit breaker frt (1 of 1)
BLK WIRE
BLU WIRE
CIRCUIT BREAKER
CIRCUIT BREAKER FRT
DOWN UP
DWN
ENGINE COMPARTMENT RELAY BOX (ON RIGHT INNER FENDER PANEL)
FRONT HEIGHT
FRONT HEIGHT LIMIT SWITCH
FRONT HEIGHT MOTOR
FRT
FUSIBLE LINK 7
GRN WIRE
HOT AT ALL TIMES
NCA WIRE
POWER SEAT SWITCH (LEFT SIDE OF SEAT)
REAR HEIGHT
REAR HEIGHT LIMIT SWITCH
REAR HEIGHT MOTOR
RECLINE
RECLINING MOTOR
RED WIRE
RR FRT
SLIDE
SLIDE LIMIT SWITCH
SLIDE MOTOR
UP DOWN
WHT WIRE
YEL WIRE
Go to component -> Power seat circuits -> CIRCUIT BREAKER FRT
