Mitsubishi Galant VIII (1996-1999) atmospheric pressure sensor 2 3 4 5 6 7 pnk Wiring diagrams

A/T ATMOSPHERIC PRESSURE SENSOR 2 3 4 5 6 7 PNK WIRE AUTO-CRUISE ECU BLK WIRE BLK/RED (A/T) WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL (M/T) WIRE BLK/YEL WIRE BLU WIRE BRN WIRE BRN/GRN WIRE BRN/RED WIRE C-35 C-41 JUNCTION BLOCK 1 CRANKSHAFT POSITION SENSOR (LEFT SIDE OF ENGINE) DATA LINK CONNECTOR (PARTIAL) (RIGHT OF STEERING COLUMN) ELC 4-SPEED AUTOMATIC TRANSAXLE CONTROL MODULE ENGINE COMPT. RELAY BOX ENGINE COOLANT TEMPERATURE SENSOR (RIGHT FRONT OF ENGINE) EVAPORATIVE EMISSION PURGE SOLENOID (IDLE) (CENTER OF SAFETY WALL) EVAPORATIVE EMISSION VENTILATION SOLENOID (RIGHT FRONT OF ENGINE COMPARTMENT) FUEL TANK DIFFERENTIAL PRESSURE SENSOR (TOP OF FUEL TANK) FUSE 12 GRN WIRE GRN/BLU WIRE GRN/RED WIRE GRN/WHT WIRE HEATED OXYGEN SENSOR (FRONT) (BELOW FRONT OF VEHICLE, ON EXHAUST MANIFOLD) HEATED OXYGEN SENSOR (REAR) (BELOW CENTER OF VEHICLE, ON EXHAUST) HOT AT ALL TIMES INTAKE AIR TEMP SENSOR JUNCTION BLOCK 2 M/T NCA WIRE PNK WIRE POWERTRAIN CONTROL MODULE (BEHIND FRONT CONSOLE) RED WIRE RED/BLK WIRE RED/WHT WIRE RED/YEL WIRE STARTING/ CHARGING SYSTEM THROTTLE POSITION SENSOR (CENTER REAR OF ENGINE COMPARTMENT) VEHICLE SPEED SENSOR (ON TRANSAXLE) VOLUME AIR FLOW SENSOR (RIGHT SIDE OF ENGINE COMPT) WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE YEL/WHT WIRE

A/T ATMOSPHERIC PRESSURE SENSOR 2 3 4 5 6 7 PNK WIRE AUTO-CRUISE ECU BLK WIRE BLK/RED (A/T) WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL (M/T) WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BRN WIRE BRN/GRN WIRE BRN/RED WIRE C-35 C-41 JUNCTION BLOCK 1 CRANKSHAFT POSITION SENSOR (LEFT SIDE OF ENGINE) DATA LINK CONNECTOR (PARTIAL) (RIGHT OF STEERING COLUMN) EGR SOLENOID (CENTER OF SAFETY WALL) ELC 4-SPEED AUTOMATIC TRANSAXLE CONTROL MODULE ENGINE COMPT. RELAY BOX ENGINE COOLANT TEMPERATURE SENSOR (RIGHT FRONT OF ENGINE) EVAPORATIVE EMISSION PURGE SOLENOID (CENTER OF SAFETY WALL) FUSE 12 GRN WIRE GRN/BLU WIRE GRN/RED WIRE GRN/WHT WIRE HEATED OXYGEN SENSOR (FRONT) (BELOW FRONT OF VEHICLE, ON EXHAUST MANIFOLD) HEATED OXYGEN SENSOR (REAR) (BELOW CENTER OF VEHICLE, ON EXHAUST) HOT AT ALL TIMES INTAKE AIR TEMP SENSOR JUNCTION BLOCK 2 M/T MANIFOLD DIFFERENTIAL PRESSURE SENSOR (REAR OF ENGINE) NCA WIRE PNK WIRE POWERTRAIN CONTROL MODULE (BEHIND FRONT CONSOLE) RED WIRE RED/BLK WIRE RED/YEL WIRE STARTING/ CHARGING SYSTEM THROTTLE POSITION SENSOR (CENTER REAR OF ENGINE COMPARTMENT) VEHICLE SPEED SENSOR (ON TRANSAXLE) VOLUME AIR FLOW SENSOR (RIGHT SIDE OF ENGINE COMPT) WHT WIRE WHT/BLK WIRE YEL WIRE YEL/GRN WIRE YEL/RED WIRE YEL/WHT WIRE
