Mitsubishi Galant VII (1992-1997) srs diagnostic unit Wiring diagrams
This page contains all the electrical diagrams for the component. srs diagnostic unit, in which he is found in the car Mitsubishi Galant VII (1992-1997). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram srs diagnostic unit (1 of 2)
Go to component -> Ground distribution circuit -> SRS DIAGNOSTIC UNIT
Wiring diagram srs diagnostic unit (2 of 2)
A/T
BATTERY
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLK/YEL WIRE
CLUTCH PEDAL POSITION SWITCH
CRUISE CONTROL SYSTEM, ENGINE CONTROL SYSTEM
ENGINE COMPARTMENT RELAY BOX
ENGINE CONTROLS SYSTEM
FUSE LINK 3
GRN/BLK WIRE
IGNITION SWITCH
JUNCTION BLOCK #2 (LEFT SIDE OF I/P)
LOCK
M/T
PARK/ NEUTRAL POSITION SWITCH (TOP OF TRANS- AXLE)
POWER DISTRIBUTION SYSTEM
RED WIRE
RUN WIRE
SRS DIAGNOSTIC UNIT
STARTER MOTOR
STARTER RELAY (RIGHT INNER FENDER PANEL)
SUPPLEMENTAL RESTRAINT SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Starting circuit -> SRS DIAGNOSTIC UNIT
