Mitsubishi Galant VII (1992-1997) slide switch tilt switch Wiring diagram
This page shows the only wiring diagram for the component.slide switch tilt switch, which is found in the car Mitsubishi Galant VII (1992-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram slide switch tilt switch (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 E-07
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
DEDICATED FUSE (UNDER- HOOD RELAY BOX) FUSE 8
DOWN UP CLOSE
FUSE 17
FUSE 8
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT IN ON OR START
HOT IN PARK HEAD OR FOG
JUNCTION BLOCK 1 (BEHIND LEFT SIDE OF DASH)
JUNCTION BLOCK 2 (BEHIND LEFT SIDE OF DASH)
LIMIT SWITCH
NCA WIRE
OFF
RED/BLK WIRE
RIGHT FRONT DOOR SWITCH (RIGHT DOOR JAMB)
SLIDE SWITCH TILT SWITCH
SUNROOF ECU (UNDER FRONT CENTER OF HEADLINER)
SUNROOF MOTOR (INSIDE HEADLINER)
SUNROOF, DOME LIGHT SWITCH (CENTER OF HEADLINER)
YEL/BLK WIRE
YEL/WHT WIRE
YEL/WHT YEL/BLK WIRE
Go to component -> Power top/sunroof circuits -> SLIDE SWITCH TILT SWITCH
