Mitsubishi Galant VII (1992-1997) remote controlled mirror switch, windshield wiper/ washer switch Wiring diagram
This page shows the only wiring diagram for the component.remote controlled mirror switch, windshield wiper/ washer switch, which is found in the car Mitsubishi Galant VII (1992-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram remote controlled mirror switch, windshield wiper/ washer switch (1 of 1)
ABS VALVE RELAY
ABS VALVE RELAY, ABS-ECU
BLK WIRE
BLK/GRN WIRE
BLK/RED (OR BLK/YEL) WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLOWER MOTOR RELAY
BLOWER SWITCH, INSIDE/OUTSIDE AIR CHANGEOVER SWITCH, AUTOMATIC COMPRESSOR ECU
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
CIGARETTE LIGHTER
CLOCK
CONDENSOR FAN HI SPEED RELAY, CONDENSOR FAN LO SPEED RELAY
DEDICATED FUSE 1
DEDICATED FUSE 11
DEDICATED FUSE 3
DEDICATED FUSE 4
DEDICATED FUSE 5
DEDICATED FUSE 9
DEFOGGER RELAY
ELECTRONIC CONTROL POWER STEERING- ECU
ENGINE COMPARTMENT RELAY BOX
ETACS-ECU (EXCEPT 1995) FUSE 9
EXCEPT 1995
FROM BATTERY (DIAGRAM 1 OF 3)
FUSE 12
FUSE 13
FUSE 14
FUSE 15
FUSE 7
FUSIBLE LINK 3
HAZARD WARNING SWITCH
HEADLIGHT RELAY (1995), HORN RELAY, HORNS
IGNITION SWITCH
JUNCTION BLOCK 1
LEFT FRONT POWER WINDOW SWITCH
LOCK
MFI RELAY
MOTOR ANTENNA ASSEMBLY
NCA WIRE
RADIO, AUTO-CRUISE ECU, CLOCK SPRING
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
REMOTE CONTROLLED MIRROR SWITCH, WINDSHIELD WIPER/ WASHER SWITCH
THEFT-ALARM HORN RELAY
TO FUSES 3,4,8 (DIAGRAM 3 OF 3)
WHT/YEL WIRE
WINDSHIELD WIPER MOTOR JUNCTION BLOCK 2
Go to component -> Power distribution circuit (2 of 3) -> REMOTE CONTROLLED MIRROR SWITCH, WINDSHIELD WIPER/ WASHER SWITCH
