Mitsubishi Galant VII (1992-1997) left front power window switch, power seat assembly Wiring diagram
This page shows the only wiring diagram for the component.left front power window switch, power seat assembly, which is found in the car Mitsubishi Galant VII (1992-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front power window switch, power seat assembly (1 of 1)
A/C COMPRESSOR RELAY
ABS MOTOR RELAY
BATTERY
BLK/RED WIRE
BLOWER MOTOR RELAY
BLU WIRE
BLU/RED WIRE
BLU/YEL WIRE
COMBINATION METER
COMBINATION METER, CLOCK
DATA LINK CONNECTOR
DEDICATED FUSE 10
DEDICATED FUSE 12
DEDICATED FUSE 6
DEDICATED FUSE 7
DEDICATED FUSE 8
DEFOGGER RELAY
ENGINE COMPARTMENT RELAY BOX
ETACS-ECU OR BUZZER-ECU
EXCEPT 1995
FOG LIGHT RELAY
FUSE 11
FUSE 17
FUSE 5
FUSE 6
FUSIBLE LINK 1
FUSIBLE LINK 2
FUSIBLE LINK 4
FUSIBLE LINK 5
FUSIBLE LINK 6
FUSIBLE LINK 7
GENERATOR
GRN/BLK WIRE
GRN/WHT WIRE
HEADLIGHT RELAY
IDLE UP DIODE, LEFT HEADLIGHT, RIGHT HEADLIGHT
JUNCTION BLOCK 1
LEFT FRONT POWER WINDOW SWITCH, POWER SEAT ASSEMBLY
PEDAL STROKE SENSOR, STOP LIGHT SWITCH SUNROOF ECU
RADIATOR FAN HI SPEED RELAY, RADIATOR FAN LO SPEED RELAY
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
STARTER MOTOR
SUNROOF SWITCH, DOME LIGHT, UNIVERSAL GARAGE DOOR OPENER
TAILLIGHT RELAY
TO FUSE LINK 3 (DIAGRAM 2 OF 3)
TRUNK ROOM LIGHT, MOTOR ANTENNA ASSEMBLY
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL/RED WIRE
Go to component -> Power distribution circuit (1 of 3) -> LEFT FRONT POWER WINDOW SWITCH, POWER SEAT ASSEMBLY
