Mitsubishi Galant VII (1992-1997) left front position, side marker Wiring diagram
This page shows the only wiring diagram for the component.left front position, side marker, which is found in the car Mitsubishi Galant VII (1992-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front position, side marker (1 of 1)
BLK WIRE
COLUMN SWITCH
DEDICATED FUSE (UNDER- HOOD RELAY BOX) FUSE 8
FUSE 5
FUSE LINK 6
FUSIBLE LINK (UNDER- HOOD RELAY BOX)
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRN/WHT WIRE
HEAD
HI MOUNT STOP LIGHT (IN REAR SPOILER)
HI MOUNT STOP LIGHT (ON REAR SHELF)
HOT AT ALL TIMES
JUNCTION BLOCK 1 (BEHIND LEFT I/P)
JUNCTION BLOCK 1 (BEHIND LEFT SIDE OF I/P)
JUNCTION BLOCK 2 (BEHIND LEFT SIDE OF I/P)
LEFT FRONT FENDER)
LEFT FRONT POSITION, SIDE MARKER
LEFT REAR COMBINATION LIGHT
LEFT REAR LICENSE LIGHT
LEFT REAR LID LIGHT
LEFT REAR SIDE MARKER LIGHT
NCA WIRE
OFF
ORG/ GRN WIRE
RED WIRE
RIGHT FRONT POSITION, SIDE MARKER
RIGHT REAR COMBINATION LIGHT
RIGHT REAR LICENSE LIGHT
RIGHT REAR LID LIGHT
RIGHT REAR SIDE MARKER LIGHT
TAIL
TAILLIGHT RELAY (UNDERHOOD RELAY BOX)
WHT WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> LEFT FRONT POSITION, SIDE MARKER
