Mitsubishi Galant VII (1992-1997) except 1995 Wiring diagrams
This page contains all the electrical diagrams for the component. except 1995, in which he is found in the car Mitsubishi Galant VII (1992-1997). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
except 1995 wiring diagram (1 of 2)
A/C COMPRESSOR RELAY
ABS MOTOR RELAY
BATTERY
BLK/RED WIRE
BLOWER MOTOR RELAY
BLU WIRE
BLU/RED WIRE
BLU/YEL WIRE
COMBINATION METER
COMBINATION METER, CLOCK
DATA LINK CONNECTOR
DEDICATED FUSE 10
DEDICATED FUSE 12
DEDICATED FUSE 6
DEDICATED FUSE 7
DEDICATED FUSE 8
DEFOGGER RELAY
ENGINE COMPARTMENT RELAY BOX
ETACS-ECU OR BUZZER-ECU
EXCEPT 1995
FOG LIGHT RELAY
FUSE 11
FUSE 17
FUSE 5
FUSE 6
FUSIBLE LINK 1
FUSIBLE LINK 2
FUSIBLE LINK 4
FUSIBLE LINK 5
FUSIBLE LINK 6
FUSIBLE LINK 7
GENERATOR
GRN/BLK WIRE
GRN/WHT WIRE
HEADLIGHT RELAY
IDLE UP DIODE, LEFT HEADLIGHT, RIGHT HEADLIGHT
JUNCTION BLOCK 1
LEFT FRONT POWER WINDOW SWITCH, POWER SEAT ASSEMBLY
PEDAL STROKE SENSOR, STOP LIGHT SWITCH SUNROOF ECU
RADIATOR FAN HI SPEED RELAY, RADIATOR FAN LO SPEED RELAY
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
STARTER MOTOR
SUNROOF SWITCH, DOME LIGHT, UNIVERSAL GARAGE DOOR OPENER
TAILLIGHT RELAY
TO FUSE LINK 3 (DIAGRAM 2 OF 3)
TRUNK ROOM LIGHT, MOTOR ANTENNA ASSEMBLY
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL/RED WIRE
Go to component -> Power distribution circuit (1 of 3) -> EXCEPT 1995
except 1995 wiring diagram (2 of 2)
ABS VALVE RELAY
ABS VALVE RELAY, ABS-ECU
BLK WIRE
BLK/GRN WIRE
BLK/RED (OR BLK/YEL) WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLOWER MOTOR RELAY
BLOWER SWITCH, INSIDE/OUTSIDE AIR CHANGEOVER SWITCH, AUTOMATIC COMPRESSOR ECU
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
CIGARETTE LIGHTER
CLOCK
CONDENSOR FAN HI SPEED RELAY, CONDENSOR FAN LO SPEED RELAY
DEDICATED FUSE 1
DEDICATED FUSE 11
DEDICATED FUSE 3
DEDICATED FUSE 4
DEDICATED FUSE 5
DEDICATED FUSE 9
DEFOGGER RELAY
ELECTRONIC CONTROL POWER STEERING- ECU
ENGINE COMPARTMENT RELAY BOX
ETACS-ECU (EXCEPT 1995) FUSE 9
EXCEPT 1995
FROM BATTERY (DIAGRAM 1 OF 3)
FUSE 12
FUSE 13
FUSE 14
FUSE 15
FUSE 7
FUSIBLE LINK 3
HAZARD WARNING SWITCH
HEADLIGHT RELAY (1995), HORN RELAY, HORNS
IGNITION SWITCH
JUNCTION BLOCK 1
LEFT FRONT POWER WINDOW SWITCH
LOCK
MFI RELAY
MOTOR ANTENNA ASSEMBLY
NCA WIRE
RADIO, AUTO-CRUISE ECU, CLOCK SPRING
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
REMOTE CONTROLLED MIRROR SWITCH, WINDSHIELD WIPER/ WASHER SWITCH
THEFT-ALARM HORN RELAY
TO FUSES 3,4,8 (DIAGRAM 3 OF 3)
WHT/YEL WIRE
WINDSHIELD WIPER MOTOR JUNCTION BLOCK 2
Go to component -> Power distribution circuit (2 of 3) -> EXCEPT 1995
