Mitsubishi Galant IX facelift (2006-2009) Manual a/c circuit, low option

A/C PRESSURE SENSOR (RIGHT FRONT OF ENGINE COMPT) A/C-ECU (BEHIND LOWER CENTER OF DASH) AIR MIXING DAMPER CONTROL MOTOR, POTENTIOMETER (BEHIND CENTER OF DASH) AIR THERMO SENSOR (BEHIND LOWER CENTER OF DASH) AMBIENT TEMPERATURE SENSOR (BEHIND LEFT SIDE OF FRONT BUMPER) BLK WIRE BLK/GRN WIRE BLK/ORG WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BLU/RED WIRE BRN WIRE BRN/WHT WIRE CONDENSER FAN RELAY (ON RELAY BOX) DEFOGGER SYSTEM FAN CONTROL RELAY (ON ENGINE COMPT RELAY BOX) FUSE 20 FUSE 22 FUSE 23 FUSIBLE LINK 2 FUSIBLE LINK 26 GRN WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HOT AT ALL TIMES HOT IN ACC OR ON HOT IN ON HOT W/ TAILLIGHT RELAY ENERGIZED J/C 2 (BEHIND INSTRUMENT CLUSTER) JOINT CONNECTOR 1 (UPPER LEFT END OF DASH) JOINT CONNECTOR 2 (BEHIND INSTRUMENT CLUSTER) JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) MODE SELECTION DAMPER CONTROL MOTOR, POTENTIOMETER (BEHIND LEFT SIDE OF DASH) NCA WIRE OUTSIDE/INSIDE AIR SELECTION DAMPER CONTROL MOTOR (BEHIND RIGHT SIDE OF DASH) RADIATOR FAN MOTOR (LEFT FRONT OF ENGINE COMPT) RADIATOR FAN RELAY (ON RELAY BOX) RED WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RELAY BOX (LEFT SIDE OF ENGINE COMPT) WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE

3 5 10 B-19 64 81 69 B-21 93 B-22 A/C COMPRESSOR ASSEMBLY A/C COMPRESSOR CLUTCH A/C COMPRESSOR CLUTCH RELAY (ON ENGINE COMPT RELAY BOX) A/C REFRIGERANT TEMPERATURE SWITCH BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLOWER MOTOR (BELOW RIGHT SIDE OF DASH) BLOWER RELAY BLOWER SWITCH BLU WIRE BLU/ORG WIRE BLU/RED WIRE C-211 C-215 DATA LINK 6 14 CONNECTOR (UNDER LEFT SIDE OF DASH) ENGINE CONTROLS SYSTEM ENGINE COOLANT TEMPERATURE FUSE FUSE 20 FUSE 6 GRN WIRE HOT AT ALL TIMES HOT IN ON JOINT CONNECTOR 2 (BEHIND INSTRUMENT CLUSTER) JOINT CONNECTOR 3 (BEHIND INSTRUMENT CLUSTER) JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) NCA WIRE OFF OFF LO ML MH POWERTRAIN CONTROL MODULE (LEFT FRONT OF ENGINE COMPT) RADIATOR SENSOR (2.4L) (MOUNTED ON RADIATOR SHROUD) RED WIRE RED/WHT WIRE RELAY BOX (LEFT SIDE OF ENGINE COMPT) RESISTOR (BEHIND CENTER OF DASH) WHT/BLK WIRE WHT/RED WIRE YEL WIRE YEL/GRN WIRE
