Mitsubishi Galant IX facelift (2006-2009) relay box (left side of engine Wiring diagram
This page shows the only wiring diagram for the component.relay box (left side of engine, which is found in the car Mitsubishi Galant IX facelift (2006-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram relay box (left side of engine (1 of 1)
ACCESSORY SOCKET 1 (+)
ACCESSORY SOCKET 2
ACCESSORY SOCKET RELAY
AIR CONDITIONING SYSTEM
AIR CONDITIONING, NAVIGATION SYSTEMS
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
COMPT)
COMPUTER DATA LINES, ENGINE CONTROLS SYSTEMS
DEFOGGER RELAY
DOOR LOCKS, INTERIOR LIGHTS SYSTEMS
ENGINE CONTROLS SYSTEM
FROM FUSE 20 (DIAGRAM 2 OF 2)
FROM FUSIBLE LINK 1 (DIAGRAM 1 OF 2)
FROM FUSIBLE LINK 4 (DIAGRAM 1 OF 2)
FUSE 10
FUSE 11
FUSE 14
FUSE 17
FUSE 20 FUSE 13
FUSE 22
FUSE 23
FUSE 24
FUSE 25
FUSE 5
FUSE 6
FUSE 9
IGNITION SWITCH
INTERIOR LIGHTS, COMPUTER DATA LINES, DOOR LOCKS,
JOINT CONNECTOR 2 (BEHIND INSTRUMENT CLUSTER)
LOCK
MIRRORS SYSTEM
RED WIRE
RELAY BOX (LEFT SIDE OF ENGINE
STARTING/ CHARGING, CRUISE CONTROL SYSTEMS
TO DEFOGGER RELAY (DIAGRAM 2 OF 2)
WHT WIRE
WIPER/WASHER SYSTEM
WIPER/WASHER SYSTEMS
YEL WIRE
Go to component -> Power distribution circuit (2 of 2) -> RELAY BOX (LEFT SIDE OF ENGINE
